Posted on

We Still Got The Wedges (#2)

featured





Re-Introducing Wedge Sconces #620 and #621,

our picks for exceptional interior lighting



Wedge Uplight Sconce #620 and #621



The holidays are over and its back to the real world! You might have missed these the first time around so let us re-introduce you to our wedge sconces! They’re Strong, Silent and Mighty Stylish!



Wedges, #620 and #621, are our picks for exceptional interior lighting. These Uplight Sconce / Wall Wash fixtures were inspired by longtime client, “Robbie”, whose inquires motivated us to create these little gems.*



The Wedges represent a perfect harmony between function and form. By working within Linear Lighting ideals our Wedges have a simple, yet elegant, design that is visually unobtrusive, yet brings a strong and reliable illumination to any installation.





Uplight Sconces #620 & 621 lighting a hallway
Uplight Wedge Sconce #620 illuminating a hallway



Once installed, the Wedges become part of the room. The enviornment. They’re there. They’re functional. But they’re not visually overbearing. Or “in the way,” as linear lighting should be! All the while brightening your world. Safely. Securely. Satisfyingly.





The Wedge Sconces are now available in 2 sizes, the original full-size option #620, 6″ H x 10″ W, and our new (Mini) “Robbie Wedge” #621, at 6″ H x 4 1/2″ W. The larger sconce is available in 2 LED options, LED12 and LED24. While the Mini is available in LED12. Both sizes offer dimmable LED control to achieve the precise lighting output needed. Constructed of 100% Aluminum, the Wedge in all versions are now available.



2 Uplight Sconces To Brighten Your World

The Wedge #620: Full-Size Uplight / Wall Washer

#620 The Wedge Uplight Sconce
The Wedge #620  | Uplight Sconce

The Wedge #620 represents a perfect harmony between function and form. By working within Linear Lighting conventions, Primelite has created an uplight sconce / Wall Wash fixture that defines, both, good design and good lighting.



#620 is the larger of the 2 Wedge designs, with a width of 10″. Constructed of 100% aluminum and available with 2 LED options, LED12 and LED24, this larger sconce offer precise lighting controls with its dimmable LEDs.



Technical Drawing: #620 LED12 | #620 LED24



our…Linear Lights ensure a long lasting, energy efficient and cost effective solution to your lighting design needs.



The Wedge #621: Mini Uplight / Wall Washer

The Wedge Mini #621  | Uplight Sconce
The Wedge Mini #621  | Uplight Sconce

The Wedge #621, AKA The “Robbie Wedge“, is the mini version of our uplight sconce / wall washer. Like its sibling, #621 is the perfect harmony between function and form. Primelite has once again created an uplight sconce / Wall Wash fixture that defines, both, good design and good lighting.



Constructed of 100% aluminum and available with a LED12, this smaller sconce offer precise lighting controls with its dimmable LEDs.



Technical Drawing: #621 LED12



Basic 3 cord wiring
Installation: Basic 3 Cord Wiring



Installation



Primelite’s Linear Collection comes pre-wired and ready to install with a basic 3 cord installation. Our Linear Lights come pre-wired, pre-tested and ready to hang! Mount! Install! Whatever you call it. We’re there!

Linear. Simple. Affordable. Strong. Easy. Dependable.



Our Wedges are handcrafted and assembled in our New York warehouse and offer years of stylish reliability. Constructed of strong aluminum, our lights are cost effective and budget friendly. All Wedges include integrated LEDs, drivers, all wiring and arrive at the job site ready to go!



Introduce a touch of color with any of our 29 powder coated colors, including chic metallic-style finishes: nickel, chrome, bronze, brass, galvanized and more.





* We’re always open to suggestions and inspiration!



2' Linear Lighting Catalog
Primelite’s 2′ Linear Lighting Catalog



Catalog: Primelite’s 2′ Linear Lighting Series (#5744)

Catalog: Primelite’s 4′ & 8′ Linear Lighting Series (#5750 & #5751)

Catalog: Primelite’s Entire Linear Lighting Series



TechSpecs

 #620 (The Wedge)

The Wedge #620  | Uplight Sconce
Primelite Catalog: #620

  • TypeLinear Light | Sconce | Wall Wash
  • Lamp: LED12 3K, 4K | LED 24 3K, 4K | Dimmable
  • Lumens:
      • LED12 3K – 1140 | LED12 4K – 1280
      • LED24 3K – 2280 | LED24 4K – 2560
  • Size: Ht 6″ | Wt 10″ | Ext 7”
  • Construction: 100% Aluminum
  • Installation: Interior | Urban Environments | Hotels | Apartment Buildings | Office Complexes | Hallways | (Inquire for Exterior Construction)
  • Mount: Wall Mounted | 1 Outlet Box
  • Finishes: Choice of 29 powder coated colors. Custom finish upon request.
  • Technical Drawing: #620 LED12 | #620 LED24

 #621 (Mini Wedge)

The Wedge Mini #621  | Uplight Sconce
Primelite Catalog: #621 (Mini) | AKA “The Robbie Wedge

  • TypeLinear Light | Sconce | Wall Wash
  • Lamp: LED12 3K, 4K| Dimmable
  • Lumens:
    • LED12 3K – 1140 | LED12 4K – 1280
  • Size: H: 6″ | W: 4½” | Ext: 7″
  • Construction: 100% Aluminum
  • Installation: Interior | Urban Environments | Hotels | Apartment Buildings | Office Complexes | Hallways | (Inquire for Exterior Construction)
  • Mount: Wall Mounted | 1 Outlet Box
  • Finishes: Choice of 29 powder coated colors. Custom finish upon request.
  • Technical Drawing: #621 LED12







Copyright 2023 Primelite Mfg.







Posted on

We’ve Got The Wedge

Have we got wedges for you





Our Wedges, #620 and #621,

are our picks for exceptional interior lighting



Wedge Uplight Sconce #620 and #621





Wedges. Of cheese. Cuts of potatos. Womans sandals. A short and sexy haircut. A lofty golf club. And now, the newest addition to Primelite’s Linear Light Collection.





Our Wedges, #620 and #621, are our picks for exceptional interior lighting. These Uplight Sconce / Wall Wash fixtures were inspired by longtime client, “Robbie”, whose inquires motivated us to create these little gems.*





The Wedges represent a perfect harmony between function and form. By working within Linear Lighting ideals our Wedges have a simple, yet elegant, design that is visually unobtrusive once installed, yet brings a strong and reliable illumination to any installation.





Uplight Sconce #620 lighting a hallway





Once installed, the Wedges becomes part of the room. The environment. It’s there. It’s functional, but it’s not visually overbearing or “in the way”. As linear lighting should be. All the while brightening your world. Safely. Securely. Satisfyingly.





The Sconces are now available in 2 sizes, the original full-size option #620, 6″ H x 10″ W, and our new (Mini) Robbie Wedge #621, at 6″ H x 4 1/2″ W. The larger sconce is available in 2 LED options, LED12 and LED24. While the Mini is available in LED12. Both sizes offer dimmable LED control to achieve the precise lighting output needed. Constructed of 100% Aluminum, the Wedge in all versions are now available.







2 Uplight Sconces To Brighten Your World



The Wedge #620: Full-Size Uplight / Wall Washer

#620 The Wedge Uplight Sconce
The Wedge #620  | Uplight Sconce

The Wedge #620 represent a perfect harmony between function and form. By working within Linear Lighting conventions Primelite has created an uplight sconce / Wall Wash fixture that defines, both, good design and good lighting.



#620 is the larger of the 2 Wedge designs, with a width of 10″. Constructed of 100% aluminum and available with 2 LED options, LED12 and LED24, this larger sconce offer precise lighting controls with its dimmable LEDs.



Technical Drawing: #620 LED12 | #620 LED24









our…Linear Lights ensure a long lasting, energy efficient and cost effective solution to your lighting design needs.



The Wedge #621: Mini Uplight / Wall Washer



The Wedge Mini #621  | Uplight Sconce
The Wedge Mini #621  | Uplight Sconce

The Wedge #621, AKA “The Robbie Wedge”, is the mini version of our uplight sconce / wall washer. And like its sibling, #621 represents the perfect harmony between function and form. Primelite has once again created an uplight sconce / Wall Wash fixture that defines, both, good design and good lighting.



Constructed of 100% aluminum and available with a LED12, this smaller sconce offer precise lighting controls with its dimmable LEDs.



Technical Drawing: #621 LED12



Basic 3 cord wiring
Installation: Basic 3 Cord Wiring



Installation



Primelite’s Linear Collection comes pre-wired and ready to install with a basic 3 cord installation. Our Linear Lights come pre-wired, pre-tested and ready to hang! Mount! Install! Whatever you call it. We’re there!

Linear. Simple. Affordable. Strong. Easy. Dependable.



Our Wedges are handcrafted and assembled in our New York warehouse and offer years of stylish reliability. Constructed of strong aluminum, our lights are cost effective and budget friendly. All Wedges include integrated LEDs, drivers, all wiring and arrive at the job site ready to go!



Introduce a touch of color with any of our 29 powder coated colors, including chic metallic-style finishes: nickel, chrome, bronze, brass, galvanized and more.





* We’re always open to suggestions and inspiration!



2' Linear Lighting Catalog
Primelite’s 2′ Linear Lighting Catalog



Catalog: Primelite’s 2′ Linear Lighting Series (#5744)

Catalog: Primelite’s 4′ & 8′ Linear Lighting Series (#5750 & #5751)

Catalog: Primelite’s Entire Linear Lighting Series



TechSpecs

 #620 (The Wedge)

The Wedge #620  | Uplight Sconce
Primelite Catalog: #620

  • TypeLinear Light | Sconce | Wall Wash
  • Lamp: LED12 | LED 24″ LED | Dimmable
  • Lumens: LED12 – 950 |  LED24 – 1900
  • Size: Ht 6″ | Wt 10″ | Ext 7”
  • Construction: 100% Aluminum
  • Installation: Interior | Urban Environments | Hotels | Apartment Buildings | Office Complexes | Hallways | (Inquire for Exterior Construction)
  • Mount: Wall Mounted | 1 Outlet Box
  • Finishes: Choice of 29 powder coated colors. Custom finish upon request.
  • Technical Drawing: #620 LED12 | #620 LED24

 #621 (Mini Wedge)

The Wedge Mini #621  | Uplight Sconce
Primelite Catalog: #621 (Mini) | AKA “The Robbie Wedge”

  • TypeLinear Light | Sconce | Wall Wash
  • Lamp: LED12 | Dimmable
  • Lumens: 950
  • Size: H: 6″ | W: 4½” | Ext: 7″
  • Construction: 100% Aluminum
  • Installation: Interior | Urban Environments | Hotels | Apartment Buildings | Office Complexes | Hallways | (Inquire for Exterior Construction)
  • Mount: Wall Mounted | 1 Outlet Box
  • Finishes: Choice of 29 powder coated colors. Custom finish upon request.
  • Technical Drawing: #621 LED12







Copyright 2022 Primelite Mfg.







Posted on

Our Linear Swivels Are Lit!

Our Linear Swivels Are Lit!

Swivel Me Right!

Swivel Me Left!

Swivel Me Mighty!

Swivel Me Brighty!



2′ Linear Lights w/ 90° Swivel



We’ve given you an introduction to some of the workhorses from our 2′ Linear light Collection. Now that we’ve established the reliable practicality of our Linears, the only thing better than one of our linear lights is our  linear lights with 90 degrees of swivel.



The addition of our 90° swivel (ESW) brings a flexibility to lighting that allows for a more precise angle of illumination.



Once the angle is achieved, easily tighten the wing nut for a permanent and secure alignment. The ESWs flexibility also allows for easy re-adjustment if the need arises.







We’re highlighting a few examples from our 2′ Linear Collection’s swivel enhanced fixtures. Linear Lights #5744/861 ESW and #5744/872 ESW are 2 wall mounted fixtures with the added flexibility of the ESW. While the Linear Light #5744/1873 ESW is a good example of a swivel affixed linear post light.



With their smaller compact size (2′), our Linear Lights have the added benefit of being installed in areas and environments where a larger silhouette just won’t do. And with the addition of a 90° swivel these “little ones” will be casting a strong, perfectly angled and secure light.



As we’ve said before. They’re small, but mighty. And as bright as any big brother. Why you might even say they’re Mighty Brighty!

2′ Linear Lights w/ 90° Swivel (ESW)



Examples of 2' Linear Lights w/ 90 degree Swivel (ESW)
Examples of 2′ Linear Lights w/ 90 degree Swivel (ESW)



The ESW is a 90° bi-directional swivel that allows for a precise angle of illumination. The swivels flexibility also allows its position to be modified at any time.



ESW 90 degree swivel
Enhance Your Linear Lights w/ a 90° Swivel (ESW)



Our 2′ Linear Lights Pack a Punch

 2′ Linear Light w/ Swivel #5744/861 ESW



linear fixture #5744/861 ESW
Linear Light w/ 90° Swivel #5744/861 ESW

Linear Light #5744/861 ESW

Linear #5744/861 ESW was designed to offer bright and efficient light where needed. The addition of a 90° swivel offers an exactitude in the angle of illumination. Its simple rectangular mount delivers an industrial design styling.



With a 24″ light box, these fixtures contain LED25 integrated diodes and drivers offering a bold output of strong, bright and inviting light. Choose lens color; white, clear or frosted. Your order comes ready to mount and is weather rated for general exterior installations.



Technical Drawing: #5744/861 ESW



 2′ Linear Light w/ Swivel #5744/872 ESW



Linear Light w/ 90° Swivel #5744/872 ESW
Linear Light w/ 90° Swivel #5744/872 ESW

Linear Light #5744/872 ESW

With its graceful arch and 90° swivel, #5744/872 brings a stylish and forceful light to our Linear Collection. The inclusion of a swivel allows for pinpoint precision of illumination.



With a 24″ light box, these fixtures contain LED25 integrated diodes and drivers offering a bold output of strong, bright and inviting light. Choose lens color; white, clear or frosted. Your order comes ready to mount and is weather rated for general exterior installations.



Technical Drawing: #5744/872 ESW



 2′ Linear Light w/ Swivel #5744/1873 ESW



Linear Light w/ 90° Swivel #5744/861 ESW
Linear Light w/ 90° Swivel #5744/1873 ESW

Linear Light #5744/1873 ESW

#5744/1873 ESW is a smaller linear light featuring a 90° swivel. Its shapely arch and integrated strip light are attached to a mount fitted for 3″ diameter posts.



With a 24″ light box containing 25W LED integrated diodes and drivers offering a bold output of strong, bright and inviting light. Choose lens color; white, clear or frosted. Your order comes ready to mount and is weather rated for general exterior installations.



Technical Drawing: #5744/1873 ESW





Our Linear Lighting collection is now available in 3 sizes – 8′ (#5751 Series), 4′ (#5750 Series) & the new 2′ (#5744 Series). Offering solutions our clientele have come to expect.
Linear Lighting collection is available in 3 sizes – 8′ (#5751 Series), 4′ (#5750 Series) & the new 2′ (#5744 Series)





Our Linear Lighting Collection is now available in 3 sizes – 8′ (#5751 Series), 4′ (#5750 Series) & the new 2′ (#5744 Series). Offering solutions our clientele have come to expect. These fixtures have been “primarily designed to improve energy efficiency and extend life” with simple yet elegant form factors for aesthetics, light optics, adaptability, and control. The inclusion of our ESW swivel allows for a precise illumination across our Linear Collection.





Basic 3 cord wiring
Installation: Basic 3 Cord Wiring



Installation



Primelite’s Linear Collection comes pre-wired and ready to install with a basic 3 cord installation. Simply put – our 2′ linear lights need only 1 outlet box (#5744 Series). The 4′ and 8′ linear lights (#5750 & #5751 Series) need 2 outlet boxes. One electrified. The other, just for fixture stability. Our Linear Lights come pre-wired, pre-tested and ready to hang! Mount! Install! Whatever you call it. We’re there!

Linear. Simple. Affordable. Strong. Easy. Dependable.



Our linear lamps are handcrafted and assembled in our New York warehouse and offer years of stylish reliability. Constructed of strong aluminum, our lights are cost effective and budget friendly. All linear fixtures include integrated LEDs, drivers, all wiring and come with a choice of lens color; white, clear or frosted. The fixtures are weather rated for general exterior installations and arrive at the job site ready to go!



Introduce a touch of color with any of our 29 powder coated colors, including chic metallic-style finishes: nickel, chrome, bronze, brass, galvanized and more.





2' Linear Lighting Catalog
Primelite’s 2′ Linear Lighting Catalog



Catalog: Primelite’s 2′ Linear Lighting Series (#5744)

Catalog: Primelite’s 4′ & 8′ Linear Lighting Series (#5750 & #5751)

Catalog: Primelite’s Entire Linear Lighting Series



TechSpecs

#5744/861 ESW

Linear Light w/ 90° Swivel #5744/861 ESW
Primelite Catalog: #5744/861 ESW

  • TypeLinear Light
  • Lamp: LED25 | 24″ LED Diode Strip
  • Lumens: 3920
  • Lens: White | Clear | Frosted
  • Size: 111/4” OAH |  24” OAL | 145/8” OAE
  • Construction: Aluminum
  • 90° Swivel: ESW
  • Installation: Commercial, Residential Environments | Smaller, Tight Spaces
  • Finishes: Choice of 29 powder coated colors. Custom finish upon request.
  • Technical Drawing: #5744/861 ESW



#5744/872 ESW

Linear Light w/ 90° Swivel #5744/872 ESW
Primelite Catalog: #5744/872 ESW

  • TypeLinear Light
  • Lamp: LED25 | 24″ LED Diode Strip
  • Lumens: 3920
  • Lens: White | Clear | Frosted
  • Size: 251/2” OAH |  24” OAL | 113/8“Ext
  • Construction: Aluminum
  • 90° Swivel: ESW
  • Installation: Commercial, Residential Environments | Smaller, Tight Spaces
  • Finishes: Choice of 29 powder coated colors. Custom finish upon request.
  • Technical Drawing: #5744/872 ESW



#5744/1873 ESW

Linear Light w/ 90° Swivel #5744/1873 ESW
Primelite Catalog: #5744/1873 ESW

  • TypeLinear Light
  • Lamp: LED25 | 24″ LED Diode Strip
  • Lumens: 3920
  • Lens: White | Clear | Frosted
  • Size: 15” OAH |  24” OAL | 9″ Ext
  • Construction: Aluminum
  • 90° Swivel: ESW
  • Mount: 3′ Post | Pole
  • Installation: Commercial, Residential Environments | Smaller, Tight Spaces
  • Finishes: Choice of 29 powder coated colors. Custom finish upon request.
  • Technical Drawing: #5744/1873 ESW





Technical Drawings

Linear Lighting #5744 Series

PDF Catalog : 2′ Linear Lighting #5744 Series

Technical Drawings: Whole Series – One PDF File







Copyright 2022 Primelite Mfg.







Posted on

The Illuminance of Our Linear Lighting

The Illuminance of Our Linear Lights

🦇 No Evening Can Resist 🦇

🦇 The Illuminance Of 🦇

🦇 Our Linears 🦇

🦇

2′ Post Mount Linear Lights 🎃



It’s always a 🦇 “thriller” 🦇 for us when we get to bring you the latest from our Linear Lighting Collection. Come and explore the newest fixtures from our 2′ Linear Lighting Series – Post Mount Linear Lights #5744/1850 and #5744/1855. You’ll be 🦇 “thrilled” 🦇 to find that these spectacular “little vessels of illuminance” are ready to offer the best in stylish, functional and affordable illumination.



With its smaller and compact size (2′), these Post Mounts can be installed into areas, and environments, where a larger silhouette wouldn’t work. When mounted atop any of our 3″ aluminum poles or posts, these “little ones” will cast a strong and secure light on the world below. They’re small, but mighty. And as bright as any big brother. Why you might even say they’re Mighty Brighty!





And Remember, “Good things, do come in smaller packages”!





Its a Thriller to introduce Post Mount Linear Light #5744/1850





Securely mounted high above streets, walkways, parks and parking, #5744/1850 and #5744/1855 will bring an efficient, and sufficient, light to any exterior setting. With its included LED25 light strip, each fixture outputs a full 3920 lumens of strong, secure luminance packed into its compact profile.





Our Linear Lighting collection is now available in 3 sizes – 8′ (#5751 Series), 4′ (#5750 Series) & the new 2′ (#5744 Series). Offering solutions our clientele have come to expect.
Linear Lighting collection is available in 3 sizes – 8′ (#5751 Series), 4′ (#5750 Series) & the new 2′ (#5744 Series)





Our Linear Lighting Collection is now available in 3 sizes – 8′ (#5751 Series), 4′ (#5750 Series) & the new 2′ (#5744 Series). Offering solutions our clientele have come to expect. These fixtures have been “primarily designed to improve energy efficiency and extend life” with simple yet elegant form factors for aesthetics, light optics, adaptability, and control.





Its a Thriller to introduce Post Mount Linear Light #5744/1855

Our 2′ Linear Lights Pack a Punch 🎃



🎃 2′ Linear Post Mount #5744/1850



Post Mount Linear Light #5744/1850
Post Mount Linear Light #5744/1850

Post Mount Linear Light #5744/1850: Our post mounted sign light comes complete with gooseneck arm #1850. Ready to offer a strong and efficient light our Post Lights are strong little guardians for security and safety along town streets, walkways, parks and other public spaces. They are designed to fit any of the wide selection of styles of our 3″ posts and poles



With a 24″ light box, these fixtures contain LED25 integrated diodes and drivers offering a bold output of strong, bright and inviting light. Choose lens color; white, clear or frosted. Your order comes ready to mount and is weather rated for general exterior installations.



The #5744/1850 model is also available with an added 90 degree swivel (ESW), #5744/1850 ESW, allowing a more precise angle of  illumination.



Technical Drawing: #5744/1850 #5744/1850 ESW





our 2′ Linear Lights ensure a long lasting, energy efficient and cost effective solution to your lighting design needs.



🎃 2′ Linear Post Mount #5744/1855



Post Mount Linear Light #5744/1855
Post Mount Linear Light #5744/1855

Post Mount Linear Light #5744/1855: Like its compadre above, #5744/1855 brings a compact solution to any lighting project. Its 24″ light box comes complete with a LED25 integrated diode light strip, drivers and all wiring. Arrives to the job site ready to mount.

Designed to fit any of our 3″ posts and poles and ships with a choice of lens color; white, clear or frosted. The fixture is weather rated for general exterior installation.



The #5744/1855 model is also available with the addition of a 90 degree swivel (ESW), #5744/1855 ESW, offering a more precise angle of  illumination.



Technical Drawings: #5744/1855 | #5744/1855 ESW





Basic 3 cord wiring
Installation: Basic 3 Cord Wiring



Installation 🎃



Primelite’s Linear Collection comes pre-wired and ready to install with a basic 3 cord installation. Simply put – our 2′ linear lights need only 1 outlet box (#5744 Series). The 4′ and 8′ linear lights (#5750 & #5751 Series) need 2 outlet boxes. One electrified. The other, just for fixture stability. Our Linear Lights come pre-wired, pre-tested and ready to hang! Mount! Install! Whatever you call it. We’re there!

Linear. Simple. Affordable. Strong. Easy. Dependable. 🎃



Our linear lamps are handcrafted and assembled in our New York warehouse and offer years of stylish reliability. Constructed of strong aluminum, our lights are cost effective and budget friendly. All linear fixtures include integrated LEDs, drivers, all wiring and come with a choice of lens color; white, clear or frosted. The fixtures are weather rated for general exterior installations and arrive at the job site ready to go!



Introduce a touch of color with any of our 29 powder coated colors, including chic metallic-style finishes: nickel, chrome, bronze, brass, galvanized and more.

🦇 Look-it! 🦇

🦇 “Its Freaken Bats!” 🦇

🦇 I Love Halloween! 🦇





2' Linear Lighting Catalog
Primelite’s 2′ Linear Lighting Catalog



Catalog: Primelite’s 2′ Linear Lighting Series (#5744)

Catalog: Primelite’s 4′ & 8′ Linear Lighting Series (#5750 & #5751)

Catalog: Primelite’s Entire Linear Lighting Series



TechSpecs

#5744/1850 🎃 | #5744/1850 ESW 🎃

linear light #5744/
Primelite Catalog: #5744/1850

  • Also available with 90° swivel –#5744/1850 ESW
  • Technical Drawing: #5744/1850 ESW

#5744/1855 🎃 | #5744/1855 ESW 🎃

linear light #5744/1855
Primelite Catalog: #5744/1855



  • Also available with 90° swivel –#5744/1855 ESW
  • Technical Drawing: #5744/1855 ESW





Technical Drawings

Linear Lighting #5744 Series

PDF Catalog : 2′ Linear Lighting #5744 Series

Technical Drawings: Whole Series – One PDF File







Copyright 2022 Primelite Mfg.







Posted on

We Made You L👀K! Up! #2

We Made You Look Pendant #5744

We Made You L👀k!

Up!



2′ Pendant Linear Light 👀



Look Up! ☝️ There’s a light to brighten the way.

Look Up! ☝️ Hanging stylishly from the rafters above, our new Linear Pendant #5744.

Look Up! ☝️Floating above, a sleek 24″ linear head suspended from strong and secure 18″ chains.

Look! ☝️ ‘Cause We Made You Look. Up!



Look up and explore the latest fixture in our new 2′ Linear Lighting Series – Linear Pendant Light #5744. These soaring “little vessels of illuminance” are ready to offer the best in stylish, functional and affordable illumination.



With a smaller compact size (2′), our Pendants can be installed in areas, and environments where a larger silhouette just won’t do. Suspended from 2 x 18″ chains, these “little ones” cast a strong and secure light.



They’re small, but mighty. And as bright as any big brother. Why you might even say they’re Mighty Brighty!





And Remember, “Good things, do come in smaller packages”!









Securely suspended above workspaces, offices, commercial spaces, and more. These beauties will bring an efficient, stylish and sufficient light to any environment. With its included LED25 light strip, each fixture outputs a full 3920 lumens of bright luminance packed into its compact profile.





Our Linear Lighting collection is now available in 3 sizes – 8′ (#5751 Series), 4′ (#5750 Series) & the new 2′ (#5744 Series). Offering solutions our clientele have come to expect.
Linear Lighting collection is available in 3 sizes – 8′ (#5751 Series), 4′ (#5750 Series) & the new 2′ (#5744 Series)





Our Linear Lighting Collection is now available in 3 sizes – 8′ (#5751 Series), 4′ (#5750 Series) & the new 2′ (#5744 Series). Offering solutions our clientele have come to expect. These fixtures have been “primarily designed to improve energy efficiency and extend life” with simple yet elegant form factors for aesthetics, light optics, adaptability, and control.





Linear Pendant Light #5744
Linear Pendant Light #5744



☝️Our 2′ Linear Lights Pack a Punch☝️



 2′ Linear Pendant #5744 👀

v
Linear Pendant Light #5744

Linear Pendant Light #5744:

Our Pendant lights would be an enhancement to any environment. Fixtures come complete with 2 x 18″ chains, introducing a strong and stylish visage to most installations.

Designed to offer bright and efficient light, whether as multiples hung throughout an open work environment or nestled snuggly within the walls of an office space. These pendants would even work as lighting elements in industrial residential spaces and lofts.



With a 24″ light box, these fixtures contain LED25 integrated diodes and drivers offering a bold output of strong, bright and inviting light. Choose lens color; white, clear or frosted. Your order comes ready to mount and is weather rated for general exterior installations.



The #5744 (Pendant) model is also available in larger sizes. 4′ – #5750 (Pendant) and 8′ – #5751 (Pendant)



Technical Drawing: #5744 (2′ Pendant)





our 2′ Linear Lights ensure a long lasting, energy efficient and cost effective solution to your lighting design needs.





Basic 3 cord wiring
Installation: Basic 3 Cord Wiring



Installation



Primelite’s Linear Collection comes pre-wired and ready to install with a basic 3 cord installation. Simply put – our 2′ linear lights need only 1 outlet box (#5744 Series). The 4′ and 8′ linear lights (#5750 & #5751 Series) need 2 outlet boxes. One electrified. The other, just for fixture stability. Our Linear Lights come pre-wired, pre-tested and ready to hang! Mount! Install! Whatever you call it. We’re there!

Linear. Simple. Affordable. Strong. Easy. Dependable.



Our linear lamps are handcrafted and assembled in our New York warehouse and offer years of stylish reliability. Constructed of strong aluminum, our lights are cost effective and budget friendly. All linear fixtures include integrated LEDs, drivers, all wiring and come with a choice of lens color; white, clear or frosted. The fixtures are weather rated for general exterior installations and arrive at the job site ready to go!



Introduce a touch of color with any of our 29 powder coated colors, including chic metallic-style finishes: nickel, chrome, bronze, brass, galvanized and more.



We Made You Look. Up!





2' Linear Lighting Catalog
Primelite’s 2′ Linear Lighting Catalog



Catalog: Primelite’s 2′ Linear Lighting Series (#5744)

Catalog: Primelite’s 4′ & 8′ Linear Lighting Series (#5750 & #5751)

Catalog: Primelite’s Entire Linear Lighting Series



TechSpecs

#5744 (Pendant) ☝️

Linear Pendant #5744 (Pendant)
Primelite Catalog: #5744 (Pendent)

  • TypeLinear Light | Hanging Pendant
  • Lamp: LED25 | 24″ LED Diode Strip
  • Lumens: 3920
  • Lens: White | Clear | Frosted
  • Size: 20” OAH |  24” OAL | 3″ W
  • Construction: Aluminum
  • Mount: Suspended from 2 x 18″ Chains
  • Installation: Commercial, Residential Environments | Smaller, Tight Spaces
  • Finishes: Choice of 29 powder coated colors. Custom finish upon request.
  • Additional Sizes Available: 4′ (#5750) | 8′ (5751)
  • Technical Drawing: #5744 (Pendant)



Technical Drawings

Linear Lighting #5744 Series

PDF Catalog : 2′ Linear Lighting #5744 Series

Technical Drawings: Whole Series – One PDF File







Copyright 2022 Primelite Mfg.







Posted on

When Two! 2! Two Linear Heads…

linear light #5744/852-2

When Two, 2, Two Heads Are Better Than One!



…Are Better Than One!



2′ 2 Headed Linear Lights



Primelite Mfg is once again at the forefront of innovation, inspiration and motivation. Introducing, the latest in an expanding selection of Linear Lighting, our new 2′ LED Linear Light Collection. These spectacular “little vessels of illuminance” are ready to offer the best in stylish, functional and affordable illumination.



This week we’re highlighting two fixtures from our new 2′ Linear Light Collection. A pair of doubled-headers, Sign Light #5744/858 ESW and its associate, #5744/852-2. With their twin 24″ LED heads (#5744A) this duo epitomizes the style, strength and function of our new Linear Lighting fixtures. They‘re small but mighty. And as bright as any big brother. Why you might even say they’re Mighty Brighty!





 They Might Be Small, But They’re Mighty Brighty!





hanging sign design
An example of an old-skool double sided sign





New Sign Light #5744/858 ESW holds a rather unique place among our Linear Collection, as it was specifically designed to illuminate a 2-sided hanging sign. Though old-skool in design, there is still a need for this type of lighting. In fact you can still find similar signs throughout urban / suburban restaurant and bar spaces, where a hanging sign can enliven, inform and entertain. Found on Main Streets, village sidewalks and in cities where space is limited. And where a double-sided sign would be considered smart marketing.





Illustration showing how fixture #5744/858 ESW would illuminate a double sided hanging sign





And Fixture #5744/858 ESW fits that need. Perfectly.





When mounted, #5744/858 ESW‘s 2 parallel heads, one on each side, will brilliantly illuminate bilateral signage. Each fixture includes 2 x 90 degree swivels (ESW), allowing a precise angle of luminescence. And of course its 2 heads offers double the light output – a full 7840 lumens (3920 per head).





Linear Light #5744/852-2 - Double Headed Parapet Mount





Fixture #5744/852-2 takes a familiar route in its lighting journey. Also designed with double Linear heads, #5744/852-2 brings its twins lights to a parapet installation. Securely mounted high above the town streets, its double heads bring twice the light to any exterior setting. A full 7840 lumens of strong, secure luminescence.





Our Linear Lighting collection is now available in 3 sizes – 8′ (#5751 Series), 4′ (#5750 Series) & the new 2′ (#5744 Series). Offering solutions our clientele have come to expect.
Linear Lighting collection is available in 3 sizes – 8′ (#5751 Series), 4′ (#5750 Series) & the new 2′ (#5744 Series)





Our Linear Lighting collection is now available in 3 sizes – 8′ (#5751 Series), 4′ (#5750 Series) & the new 2′ (#5744 Series). Offering solutions our clientele have come to expect. These fixtures have been “primarily designed to improve energy efficiency and extend life” with simple yet elegant form factors for aesthetics, light optics, adaptability, and control.



2′ Linear Lights Pack a Punch



2′ Linear Light Twin Headed #5744/858 ESW



linear light #5744/858
Twin Headed Linear Light #5744/858 ESW

#5744/858 ESW: As mentioned above, Sign Light #5744/858 ESW has a rather unique place among the Linear Collection, specifically to illuminate 2-sided hanging signage. This type of fixture is popular, especially in towns and cities where a double sided hanging sign can be considered smart marketing.

With 2 x 24″ light boxes, these fixtures comes complete with 2 x LED25 integrated diodes and drivers offering a bold output of strong, bright and inviting light. Your order comes with a choice of lens color, white, clear or frosted. The fixture is weather rated for general exterior installations.



Technical Drawing: #5744/858 ESW





our 2′ Linear Lights ensure a long lasting, energy efficient and cost effective solution to your lighting design needs.



2′ Linear Light Parapet Mount #5744/852-2



linear light #5744/852-2
Linear Light Parapet Mount #5744/852-2

#5744/852-2: Like its compadre above, #5744/852-2 brings a two headed solution to any lighting project. While the Linear lighting output and head design are similar, the difference is in the fixtures mount. #5744/852-2 is designed to be parapet mounted, sitting atop buildings and roofs throughout town.

Its 24″ light boxes comes complete with 2 X LED25 strips of integrated diodes and drivers. And ships with a choice of  lens color, white, clear or frosted.



The #5744/852-2 model is also available with the addition of 2 x 90 degree swivels (ESW), #5744/852-2 ESW, for a more precise illumination.



Technical Drawing: #5744/852-2



Basic 3 cord wiring
Installation: Basic 3 Cord Wiring



Installation



Primelite’s Linear Collection comes pre-wired and ready to install with a basic 3 cord installation. Simply put – our 2′ linear lights need only 1 outlet box (#5744 Series). The 4′ and 8′ linear lights (#5750 & #5751 Series) need 2 outlet boxes. One electrified. The other, just for fixture stability. Our Linear Lights come pre-wired, pre-tested and ready to hang! Mount! Install! Whatever you call it. We’re there!

Linear. Simple. Affordable. Strong. Easy. Dependable.



Our linear lamps are handcrafted and assembled in our New York warehouse and offer years of stylish reliability. Constructed of strong aluminum, our lights are cost effective and budget friendly. All linear fixtures include integrated LEDs, drivers, all wiring and come with a choice of lens color; white, clear or frosted. The fixtures are weather rated for general exterior installations and arrive at the job site ready to go!



Introduce a touch of color with any of our 29 powder coated colors, including chic metallic-style finishes: nickel, chrome, bronze, brass, galvanized and more.





2' Linear Lighting Catalog
Primelite’s 2′ Linear Lighting Catalog



Catalog: Primelite’s 2′ Linear Lighting Series (#5744)

Catalog: Primelite’s 4′ & 8′ Linear Lighting Series (#5750 & #5751)

Catalog: Primelite’s Entire Linear Lighting Series



TechSpecs

#5744/858 ESW

linear light #5744/858 ESW
Primelite Catalog: #5744/858 ESW

  • TypeLinear Light | Double Headed
  • Lamp: 2 x LED25 | 2 x 24″ LED Diode Strip
  • Lumens: 7840 (2 x LED25 | 3920)
  • Lens: White | Clear | Frosted
  • Swivel: 2 x 90° swivels
  • Size: 12 3/8” OAH | 24 5/8” OAE | 23” OAL
  • Construction: Aluminum
  • Installation: Cities, Urban Environments | Smaller, Tight Exterior Spaces
  • Mount: Wall Mounted | 1 Outlet Box
  • Finishes: Choice of 29 powder coated colors. Custom finish upon request.
  • Technical Drawing: #5744/858 ESW

#5744/852-2 (Double Headed | Parapet Mount)

Linear Light #5744/852-2
Primelite Catalog: #5744/852-2

  • TypeLinear Light | Double Headed
  • Lamp: 2 x LED25 | 2 x 24″ LED Diode Strip
  • Lumens: 7840 (2 x LED25 | 3920)
  • Lens: White | Clear | Frosted
  • Size24 1/8” OAH | 31 3/4” OAE | 24” OAL
  • Construction: Aluminum
  • Installation: Cities, Urban Environments | Smaller, Tight Exterior Spaces
  • Mount: Parapet | 1 Outlet Box
  • Finishes: Choice of 29 powder coated colors. Custom finish upon request.
  • Technical Drawing: #5744/852-2





Technical Drawings

Linear Lighting #5744 Series

PDF Catalog : 2′ Linear Lighting #5744 Series

Technical Drawings: Whole Series – One PDF File







Copyright 2022 Primelite Mfg.







Posted on

Mighty Brighty Linear Lighting

Ceiling mount linear lights #5744F & #5744/18

Flush Mount Linear Light #5744F

Mounts | Ceiling | Flush | Stem



2′ Linear Lights Ceiling Mount



Primelite Mfg is once again at the forefront of innovation, inspiration and motivation. Introducing, the latest in an expanding selection of Linear Lighting, our new 2′ LED Linear Light Collection. These spectacular “little vessels of illuminance” are ready to offer the best in stylish, functional and affordable illumination.



This week we are featuring 2 new fixtures from the 2′ Linear Light #5744 Series, flush mounted #5744F and its compadre, stem-mounted #5744/18 (also known as #5744S). With their 24″ ceiling mounted heads (#5744A) this duo epitomizes the style, strength and function of our new Linear Lighting fixtures. They‘re small but mighty. And as bright as any big brother. Why they’re …



Mighty Brighty!





And Remember, “Our Good things, do come in smaller packages”!



Stem Mount Linear Light #5744/18





Our Linear Lighting collection is now available in 3 sizes – 8′ (#5751 Series), 4′ (#5750 Series) & the new 2′ (#5744 Series). Offering solutions our clientele have come to expect. These fixtures have been “primarily designed to improve energy efficiency and extend life” with simple yet elegant form factors for aesthetics, light optics, adaptability, and control.





Our 2′ Linear Light #5744 Series‘ flush mounted #5744F and stem-mounted #5744/18 (#5744Sare now ready to light your life. We also offer these ceiling mounted light fixtures in larger sizes if a project calls for it.



In our 8′ series (#5751) we carry flush mounted #5751F and its friend, #5751/18, with 18″ stems. On the 4′ side of things (Series #5750) we have flush mounted fixture #5750F and ceiling mounted #5750/18. Again with 18′ stems.





Mighty Brighty Stem Mount Linear Light #5744F





No matter your projects  needs and environment, we have a size and illumination to get the job done. Quickly, brightly and economically! And with Primelite’s renowned reliability.

2′ Linear Lights Pack a Punch



…it might be small, but it’s mighty brighty!”



Any of our new 2′ Linear Lights packs an illuminating punch when it comes to light output. The LED25 diode strip, only 24″ long, offers a broad field of light, far beyond its small footprint. Our new fixtures are small, secure and weather-strong, offering an illumination to rival the big guys. Proving once again, they might be small, but they’re mighty brighty!





Mighty Brighty Flush Mount Linear Light #5744F





Our 2′ Linear Light collection, in fact all of the collections are maintenance free, economically affordable, easily installed, and includes Primelite’s superior construction. Fixtures range from flush mounted to wall washers. From outstanding post lights to easily adjustable multi-use fixtures. All fixtures include LED diodes and drivers, come pre-wired and arrive at the job site ready to install. Simple. Affordable. Strong. Easy. Dependable.



2′ Linear Light Flush Mounted #5744F



linear light #5744F | flush mount
Flush Mount Linear Light #5744F

Flush-mounted Linear Light #5744F: The perfect, ceiling flush mounted fixture, physically smaller than its larger brothers, #5750F and #5751F, but with oversized lighting. Ideal for commercial lighting and general illumination; install in small areas that need big light.



With a light box of 24″, it comes complete with a LED25 strip of integrated diodes and driver offering a bold output of strong, bright light.



And while shown with a clear lens (-4), your order comes with a choice of a lens color, white, clear or frosted. The fixture is weather rated for general exterior installations.



Technical Drawing: #5744F





our 2′ Linear Lights ensure a long lasting, energy efficient and cost effective solution to your lighting design needs.



2′ Linear Light Stem Mounted #5744/18 (#5744S)



linear light #5744S | Stem mounted
Stem Mount Linear Light #5744S

Stem Mounted Linear Light #5744/18 (#5744S) : Like its compadre above,  #5744/18 offers the same size, structure and illuminance of #5744F, but instead of a ceiling flush mount, this fixture is suspended by an 18″ stem.



With a 24″ light box it comes complete with a LED25 strip of integrated diodes and driver. And comes with a choice of  lens color, white, clear or frosted.



BTW – #5744/18 is also know as #5744S, “S” for stem mount.



Technical Drawing: #5744/18



Basic 3 cord wiring
Installation: Basic 3 Cord Wiring



Installation



Primelite’s Linear Collection comes pre-wired and ready to install with a basic 3 cord installation. Simply put – our 2′ linear lights need only 1 outlet box (#5744 Series). The 4′ and 8′ linear lights (#5750 & #5751 Series) need 2 outlet boxes. One electrified. The other, just for fixture stability. Our Linear Lights come pre-wired, pre-tested and ready to hang! Mount! Install! Whatever you call it. We’re there!

Linear. Simple. Affordable. Strong. Easy. Dependable.



Our linear lamps are handcrafted and assembled in our New York warehouse and offer years of stylish reliability. Constructed of strong aluminum, our lights are cost effective and budget friendly. All linear fixtures include integrated LEDs, drivers, all wiring and come with a choice of lens color; white, clear or frosted. The fixtures are weather rated for general exterior installations and arrive at the job site ready to go!



Introduce a touch of color with any of our 29 powder coated colors, including chic metallic-style finishes: nickel, chrome, bronze, brass, galvanized and more.





TechSpecs

 #5744F (Flush Mounted)

Linear Light #5744F
Primelite Catalog: #5744F

TypeLinear Light | Flush Mount

Lamp: LED25 | 24″ LED Diode Strip

Lens: White | Clear | Frosted

Size: 4 1/2″ OAH | 3″ OAW | 24″ OAL

Construction: Aluminum



Installation: Ceiling Mounted | Smaller, Tight Exterior Spaces
Finishes: Choice of 29 powder coated colors. Custom finish upon request.
Technical Drawing: #5744F

 #5744/18 (Stem Mounted)

Linear Light #5744S | #5744/18
Primelite Catalog: #5744/18 (#5744S*)

*(#5744/18 is also known as #5744S. “S” for stem mount)

Type: Linear Light | Stem-Mount

Lamp: LED25 | 24″ LED Diode Strip

Lens: White | Clear | Frosted

Stem: 18″

Size: 22 5/8″ OAH | 3″ OAW | 24″ OAL

Construction: Aluminum



Installation: Ceiling Mount | Smaller, Tight Exterior Spaces
Finishes: Choice of 29 powder coated colors. Custom finish upon request
Technical Drawing: #5744/18



Linear Lighting #5744 Series Technical Drawing:

Whole Series – One PDF File







Copyright 2022 Primelite Mfg.
