Posted on

When Two! 2! Two Linear Heads…

linear light #5744/852-2

When Two, 2, Two Heads Are Better Than One!



…Are Better Than One!



2′ 2 Headed Linear Lights



Primelite Mfg is once again at the forefront of innovation, inspiration and motivation. Introducing, the latest in an expanding selection of Linear Lighting, our new 2′ LED Linear Light Collection. These spectacular “little vessels of illuminance” are ready to offer the best in stylish, functional and affordable illumination.



This week we’re highlighting two fixtures from our new 2′ Linear Light Collection. A pair of doubled-headers, Sign Light #5744/858 ESW and its associate, #5744/852-2. With their twin 24″ LED heads (#5744A) this duo epitomizes the style, strength and function of our new Linear Lighting fixtures. They‘re small but mighty. And as bright as any big brother. Why you might even say they’re Mighty Brighty!





 They Might Be Small, But They’re Mighty Brighty!





hanging sign design
An example of an old-skool double sided sign





New Sign Light #5744/858 ESW holds a rather unique place among our Linear Collection, as it was specifically designed to illuminate a 2-sided hanging sign. Though old-skool in design, there is still a need for this type of lighting. In fact you can still find similar signs throughout urban / suburban restaurant and bar spaces, where a hanging sign can enliven, inform and entertain. Found on Main Streets, village sidewalks and in cities where space is limited. And where a double-sided sign would be considered smart marketing.





Illustration showing how fixture #5744/858 ESW would illuminate a double sided hanging sign





And Fixture #5744/858 ESW fits that need. Perfectly.





When mounted, #5744/858 ESW‘s 2 parallel heads, one on each side, will brilliantly illuminate bilateral signage. Each fixture includes 2 x 90 degree swivels (ESW), allowing a precise angle of luminescence. And of course its 2 heads offers double the light output – a full 7840 lumens (3920 per head).





Linear Light #5744/852-2 - Double Headed Parapet Mount





Fixture #5744/852-2 takes a familiar route in its lighting journey. Also designed with double Linear heads, #5744/852-2 brings its twins lights to a parapet installation. Securely mounted high above the town streets, its double heads bring twice the light to any exterior setting. A full 7840 lumens of strong, secure luminescence.





Our Linear Lighting collection is now available in 3 sizes – 8′ (#5751 Series), 4′ (#5750 Series) & the new 2′ (#5744 Series). Offering solutions our clientele have come to expect.
Linear Lighting collection is available in 3 sizes – 8′ (#5751 Series), 4′ (#5750 Series) & the new 2′ (#5744 Series)





Our Linear Lighting collection is now available in 3 sizes – 8′ (#5751 Series), 4′ (#5750 Series) & the new 2′ (#5744 Series). Offering solutions our clientele have come to expect. These fixtures have been “primarily designed to improve energy efficiency and extend life” with simple yet elegant form factors for aesthetics, light optics, adaptability, and control.



2′ Linear Lights Pack a Punch



2′ Linear Light Twin Headed #5744/858 ESW



linear light #5744/858
Twin Headed Linear Light #5744/858 ESW

#5744/858 ESW: As mentioned above, Sign Light #5744/858 ESW has a rather unique place among the Linear Collection, specifically to illuminate 2-sided hanging signage. This type of fixture is popular, especially in towns and cities where a double sided hanging sign can be considered smart marketing.

With 2 x 24″ light boxes, these fixtures comes complete with 2 x LED25 integrated diodes and drivers offering a bold output of strong, bright and inviting light. Your order comes with a choice of lens color, white, clear or frosted. The fixture is weather rated for general exterior installations.



Technical Drawing: #5744/858 ESW





our 2′ Linear Lights ensure a long lasting, energy efficient and cost effective solution to your lighting design needs.



2′ Linear Light Parapet Mount #5744/852-2



linear light #5744/852-2
Linear Light Parapet Mount #5744/852-2

#5744/852-2: Like its compadre above, #5744/852-2 brings a two headed solution to any lighting project. While the Linear lighting output and head design are similar, the difference is in the fixtures mount. #5744/852-2 is designed to be parapet mounted, sitting atop buildings and roofs throughout town.

Its 24″ light boxes comes complete with 2 X LED25 strips of integrated diodes and drivers. And ships with a choice of  lens color, white, clear or frosted.



The #5744/852-2 model is also available with the addition of 2 x 90 degree swivels (ESW), #5744/852-2 ESW, for a more precise illumination.



Technical Drawing: #5744/852-2



Basic 3 cord wiring
Installation: Basic 3 Cord Wiring



Installation



Primelite’s Linear Collection comes pre-wired and ready to install with a basic 3 cord installation. Simply put – our 2′ linear lights need only 1 outlet box (#5744 Series). The 4′ and 8′ linear lights (#5750 & #5751 Series) need 2 outlet boxes. One electrified. The other, just for fixture stability. Our Linear Lights come pre-wired, pre-tested and ready to hang! Mount! Install! Whatever you call it. We’re there!

Linear. Simple. Affordable. Strong. Easy. Dependable.



Our linear lamps are handcrafted and assembled in our New York warehouse and offer years of stylish reliability. Constructed of strong aluminum, our lights are cost effective and budget friendly. All linear fixtures include integrated LEDs, drivers, all wiring and come with a choice of lens color; white, clear or frosted. The fixtures are weather rated for general exterior installations and arrive at the job site ready to go!



Introduce a touch of color with any of our 29 powder coated colors, including chic metallic-style finishes: nickel, chrome, bronze, brass, galvanized and more.





2' Linear Lighting Catalog
Primelite’s 2′ Linear Lighting Catalog



Catalog: Primelite’s 2′ Linear Lighting Series (#5744)

Catalog: Primelite’s 4′ & 8′ Linear Lighting Series (#5750 & #5751)

Catalog: Primelite’s Entire Linear Lighting Series



TechSpecs

#5744/858 ESW

linear light #5744/858 ESW
Primelite Catalog: #5744/858 ESW

  • TypeLinear Light | Double Headed
  • Lamp: 2 x LED25 | 2 x 24″ LED Diode Strip
  • Lumens: 7840 (2 x LED25 | 3920)
  • Lens: White | Clear | Frosted
  • Swivel: 2 x 90° swivels
  • Size: 12 3/8” OAH | 24 5/8” OAE | 23” OAL
  • Construction: Aluminum
  • Installation: Cities, Urban Environments | Smaller, Tight Exterior Spaces
  • Mount: Wall Mounted | 1 Outlet Box
  • Finishes: Choice of 29 powder coated colors. Custom finish upon request.
  • Technical Drawing: #5744/858 ESW

#5744/852-2 (Double Headed | Parapet Mount)

Linear Light #5744/852-2
Primelite Catalog: #5744/852-2

  • TypeLinear Light | Double Headed
  • Lamp: 2 x LED25 | 2 x 24″ LED Diode Strip
  • Lumens: 7840 (2 x LED25 | 3920)
  • Lens: White | Clear | Frosted
  • Size24 1/8” OAH | 31 3/4” OAE | 24” OAL
  • Construction: Aluminum
  • Installation: Cities, Urban Environments | Smaller, Tight Exterior Spaces
  • Mount: Parapet | 1 Outlet Box
  • Finishes: Choice of 29 powder coated colors. Custom finish upon request.
  • Technical Drawing: #5744/852-2





Technical Drawings

Linear Lighting #5744 Series

PDF Catalog : 2′ Linear Lighting #5744 Series

Technical Drawings: Whole Series – One PDF File







Copyright 2022 Primelite Mfg.







Posted on

Mighty Brighty Linear Lighting

Ceiling mount linear lights #5744F & #5744/18

Flush Mount Linear Light #5744F

Mounts | Ceiling | Flush | Stem



2′ Linear Lights Ceiling Mount



Primelite Mfg is once again at the forefront of innovation, inspiration and motivation. Introducing, the latest in an expanding selection of Linear Lighting, our new 2′ LED Linear Light Collection. These spectacular “little vessels of illuminance” are ready to offer the best in stylish, functional and affordable illumination.



This week we are featuring 2 new fixtures from the 2′ Linear Light #5744 Series, flush mounted #5744F and its compadre, stem-mounted #5744/18 (also known as #5744S). With their 24″ ceiling mounted heads (#5744A) this duo epitomizes the style, strength and function of our new Linear Lighting fixtures. They‘re small but mighty. And as bright as any big brother. Why they’re …



Mighty Brighty!





And Remember, “Our Good things, do come in smaller packages”!



Stem Mount Linear Light #5744/18





Our Linear Lighting collection is now available in 3 sizes – 8′ (#5751 Series), 4′ (#5750 Series) & the new 2′ (#5744 Series). Offering solutions our clientele have come to expect. These fixtures have been “primarily designed to improve energy efficiency and extend life” with simple yet elegant form factors for aesthetics, light optics, adaptability, and control.





Our 2′ Linear Light #5744 Series‘ flush mounted #5744F and stem-mounted #5744/18 (#5744Sare now ready to light your life. We also offer these ceiling mounted light fixtures in larger sizes if a project calls for it.



In our 8′ series (#5751) we carry flush mounted #5751F and its friend, #5751/18, with 18″ stems. On the 4′ side of things (Series #5750) we have flush mounted fixture #5750F and ceiling mounted #5750/18. Again with 18′ stems.





Mighty Brighty Stem Mount Linear Light #5744F





No matter your projects  needs and environment, we have a size and illumination to get the job done. Quickly, brightly and economically! And with Primelite’s renowned reliability.

2′ Linear Lights Pack a Punch



…it might be small, but it’s mighty brighty!”



Any of our new 2′ Linear Lights packs an illuminating punch when it comes to light output. The LED25 diode strip, only 24″ long, offers a broad field of light, far beyond its small footprint. Our new fixtures are small, secure and weather-strong, offering an illumination to rival the big guys. Proving once again, they might be small, but they’re mighty brighty!





Mighty Brighty Flush Mount Linear Light #5744F





Our 2′ Linear Light collection, in fact all of the collections are maintenance free, economically affordable, easily installed, and includes Primelite’s superior construction. Fixtures range from flush mounted to wall washers. From outstanding post lights to easily adjustable multi-use fixtures. All fixtures include LED diodes and drivers, come pre-wired and arrive at the job site ready to install. Simple. Affordable. Strong. Easy. Dependable.



2′ Linear Light Flush Mounted #5744F



linear light #5744F | flush mount
Flush Mount Linear Light #5744F

Flush-mounted Linear Light #5744F: The perfect, ceiling flush mounted fixture, physically smaller than its larger brothers, #5750F and #5751F, but with oversized lighting. Ideal for commercial lighting and general illumination; install in small areas that need big light.



With a light box of 24″, it comes complete with a LED25 strip of integrated diodes and driver offering a bold output of strong, bright light.



And while shown with a clear lens (-4), your order comes with a choice of a lens color, white, clear or frosted. The fixture is weather rated for general exterior installations.



Technical Drawing: #5744F





our 2′ Linear Lights ensure a long lasting, energy efficient and cost effective solution to your lighting design needs.



2′ Linear Light Stem Mounted #5744/18 (#5744S)



linear light #5744S | Stem mounted
Stem Mount Linear Light #5744S

Stem Mounted Linear Light #5744/18 (#5744S) : Like its compadre above,  #5744/18 offers the same size, structure and illuminance of #5744F, but instead of a ceiling flush mount, this fixture is suspended by an 18″ stem.



With a 24″ light box it comes complete with a LED25 strip of integrated diodes and driver. And comes with a choice of  lens color, white, clear or frosted.



BTW – #5744/18 is also know as #5744S, “S” for stem mount.



Technical Drawing: #5744/18



Basic 3 cord wiring
Installation: Basic 3 Cord Wiring



Installation



Primelite’s Linear Collection comes pre-wired and ready to install with a basic 3 cord installation. Simply put – our 2′ linear lights need only 1 outlet box (#5744 Series). The 4′ and 8′ linear lights (#5750 & #5751 Series) need 2 outlet boxes. One electrified. The other, just for fixture stability. Our Linear Lights come pre-wired, pre-tested and ready to hang! Mount! Install! Whatever you call it. We’re there!

Linear. Simple. Affordable. Strong. Easy. Dependable.



Our linear lamps are handcrafted and assembled in our New York warehouse and offer years of stylish reliability. Constructed of strong aluminum, our lights are cost effective and budget friendly. All linear fixtures include integrated LEDs, drivers, all wiring and come with a choice of lens color; white, clear or frosted. The fixtures are weather rated for general exterior installations and arrive at the job site ready to go!



Introduce a touch of color with any of our 29 powder coated colors, including chic metallic-style finishes: nickel, chrome, bronze, brass, galvanized and more.





TechSpecs

 #5744F (Flush Mounted)

Linear Light #5744F
Primelite Catalog: #5744F

TypeLinear Light | Flush Mount

Lamp: LED25 | 24″ LED Diode Strip

Lens: White | Clear | Frosted

Size: 4 1/2″ OAH | 3″ OAW | 24″ OAL

Construction: Aluminum



Installation: Ceiling Mounted | Smaller, Tight Exterior Spaces
Finishes: Choice of 29 powder coated colors. Custom finish upon request.
Technical Drawing: #5744F

 #5744/18 (Stem Mounted)

Linear Light #5744S | #5744/18
Primelite Catalog: #5744/18 (#5744S*)

*(#5744/18 is also known as #5744S. “S” for stem mount)

Type: Linear Light | Stem-Mount

Lamp: LED25 | 24″ LED Diode Strip

Lens: White | Clear | Frosted

Stem: 18″

Size: 22 5/8″ OAH | 3″ OAW | 24″ OAL

Construction: Aluminum



Installation: Ceiling Mount | Smaller, Tight Exterior Spaces
Finishes: Choice of 29 powder coated colors. Custom finish upon request
Technical Drawing: #5744/18



Linear Lighting #5744 Series Technical Drawing:

Whole Series – One PDF File







Copyright 2022 Primelite Mfg.







Posted on

Our New 2′ Linear Lights Are Mighty Brighty!

New 2' Liner Lighting Collection (#5744 Series)



The “illumination effect (of Linear Lighting) is subtle, with a soft, uniform, highly efficient glow of light…the focus is on light, not light sources.



Primelite Mfg, always at the forefront of innovation, inspiration and motivation, introduces a new series in our expanding selection of Linear Lighting. The “2′ LED Linear Light Collection” (#5744 Series). These spectacular “little vessels of illuminance” are ready to offer the best in stylish, functional and affordable illumination.



2′ Linear Lights Pack a Punch



Our new 2′ Linear Light Collection packs an illuminating punch when it comes to actual light output. The #5744’s LED25 diode strip, might only be 24″ long but its output offers a broad field of light far beyond its small footprint. For example, when mounted on a 7′ post, the output is equivalent to at least a 10′ spread of light. Proving they may be small, but they’re mighty brighty!





And Remember, “Our Good things, do come in smaller packages”!



New 2' Linear Lighting Collection (#5744 Series)
New 2′ Linear Lighting Collection (#5744 Series)



2′ Linear Light Collection



(our) Linear Lighting collection is…available in 3 size options – 8′ (#5751 Series), 4′ (#5750 Series) &…2′ (#5744 Series)



The Linear Lighting collection is now available in 3 size options – 8′ (#5751 Series), 4′ (#5750 Series) & the new 2′ (#5744 Series). Our Linear Lights offer solutions that our clientele have come to expect. These fixtures have been “designed to improve energy efficiency and extend life” with simple yet elegant form factors for aesthetics, light optics, adaptability, and control.





New 2' Liner Lighting Collection (#5744 Series)
Linear Lighting Collection – 3 Sizes: 8′ (Series #5751), 4′ (Series #5750) & 2′ Series (#5744) – Wall Wash Models Shown #5751WW (8′) | #5750WW (4′) | #5744WW (2′)





Whether crafted as a pendant suspended sturdily from above, securely extending from its wall mount or a post light firmly mounted atop its post / pole, every fixture offers its own stylish interpretation of linear lighting with illumination to rival the big guys.





Our 2′ linear collection, in fact all of the linear collections, are maintenance free, economically affordable, easily installed, and feature Primelite superior construction. Fixtures range from flush & ceiling mount to wall washers. From strong and secure post lights to easily adjustable multi-use fixtures. All linear fixtures (all sizes) include LED diodes, drivers, come pre-wired and arrive ready to install.



Our New Linear Lighting 2' Fixtures. Small But Mighty!



our 2′ Linear Lights ensure a long lasting, energy efficient and cost effective solution to your lighting design needs.

Linear. Simple. Affordable. Strong. Easy. Dependable.



Our linear lamps are handcrafted and assembled in our New York warehouse and offer years of stylish reliability. Constructed of strong aluminum, our lights are cost effective and budget friendly. All linear fixtures include integrated LEDs, drivers, all wiring and come with a choice of lens color; white, clear or frosted. The fixtures are weather rated for general exterior installations and arrive at the job site ready to go!



Introduce a touch of color with any of our 29 powder coated colors, including chic metallic-style finishes: nickel, chrome, bronze, brass, galvanized and more.



TechSpecs (2′ Linear Series Examples)



Linear Light #5744F

Flush Ceiling Mount #5744F

Technical Drawing: 5744F

Linear Light #5744S

Stem Mounted #5744S

Technical Drawing: 5744S



Linear Light #5744-855-ESW

#5744/855-ESW

Technical Drawing: 5744/855-ESW

Linear Light #5744 Pendant

#5744 PENDANT

Technical Drawing: 5744 Pendant

Linear Light #5744/858-ESW

#5744/858-ESW

Technical Drawing: 5744/858-ESW

Linear Light #5744-1873-ESW

#5744/1873-ESW

Technical Drawing: 5744/1873-ESW-LED25







Copyright 2022 Primelite Mfg.





Posted on

Our Linear Lights Are “One And Done”

One and Done. Linear Lighting Installation

blank

A Quick and Easy Installation



One & Done: Linear Light Installation



“One and done!” Our rallying cry to herald the ease of installation for Primelite’s New Linear Light Collection. Simply put – our 4′ & 8′ linear lights need only be installed with 2 outlet boxes. One electrified. The other, just for fixture stability. Our Linear Lights come pre-wired, pre-tested and ready to hang! Mount! Install! Whatever you call it. We’re there!



One & Done: Linear Light Collection



Primelite Mfg is once again at the forefront of innovation, inspiration and motivation. Let us reacquaint you with our expanding selection of Linear Lighting. Our collection is now available in 3 length options for the perfect installation. We offer 8′ (#5751 Series), 4′ (#5750 Series), and our newest collection, 2′ fixtures (#5477 Series). Each Linear Light, irregardless of size, is ready to offer a stylish, functional and affordable illumination.



linear light #5744WW
An example of Linear Light Head #5751 fixture – Wall Mount #5751WW (wall washer)



Each Linear Light, irregardless of size, is ready to offer the best in stylish, functional and affordable illumination.



Primelite's Linear Light Collection - 4', 8'
Primelite’s Linear Light Collection – #5750 (4′), #5751 (8′)



Our 8′ Linear Light Collection offers 2 head options; #5751 and #5796



Our 8′ Linear Light Collection offers 2 head options; #5751 and #5796. The #5751 model is a simple, utilitarian, all aluminum, rectangle of light in 3 sizes options. The #5796 fixture delivers a softer flow with its rounded back and more subtle design. Offering a bit more style while not interfering with “line of sight”. The true purpose of a linear lighting installation.



Every Primelite linear fixture comes pre-wired, and pre-tested, to ensure a painless installation. All 4′ and 8′ fixtures need 2 electrical outlets for installation. One electrified. One dummy for stability. Arriving pre-wired ensures that the installation is truly “one and done“! As simple as 1, 2…!





linear light sign light #5796
Linear Light Sign Light #5796



One and Done: Linear Light Heads #5750 & #5751





linear light head #5744
Linear Light Head #5751. Shown as part of fixture #5751WW

Linear Light Heads #5750 & #5751 : (Shown #5751WW) A perfect, simple, fixture. Available in 4″ (#5750) & 8′ (#5751) lengths. Each head includes LED diode strip light, drivers and wiring installed and pre-tested.



We offer fixture combinations with some of our most popular arms to ensure a stylish and functional light. (models listed below)*



With light boxes of 50″ (4′) or 96″ (8′), the fixtures come complete with pre-installed integrated diodes, drivers, and all necessary wiring. And while the 4′ and 8′ fixtures need 2 electrical outlets for installation, only one needs electrification!



All Linear Light fixtures are available with a choice of lens color:  clear, white or frosted. And all fixtures are weather rated for general exterior installations.



Utilitarian in both design and function, #5796 offers a strong and bright spread of LED illumination



One and Done: Linear Light #5796



linear light #5796
Linear Sign Light #5796

Linear Light #5796: Utilitarian in both design and function, the 8′ #5796 offers a strong and bright spread of LED52 illumination. A 4′ version (#5748) is also available. Both include clear lens.



The #5796 & #5748 lights include 2 – 90° swivels for accurate and precise positioning, making this fixture perfect for lighting larger signs, storefronts and wall washings. In fact consider this fixture for use in parking lots, alleyways, anywhere strong, and cost-effective, lighting is needed.



Our linear lamps are handcrafted and assembled in our New York warehouse and offer years of stylish reliability, are cost effective and budget friendly. All fixtures include integrated LEDs  offering very efficient lumens per watt! Introduce a touch of color with any of our 29 powder coated colors, including chic metallic-style finishes: nickel, chrome, bronze, brass, galvanized and more.



  • The Linear Light Collection (4′ & 8′) | #5750 and #5751 series include:
  1. #5750F LED50 / #5751F LED50/100–  Ceiling flush mount (product)
  2. #5750WW LED50 / #5751WW LED50/100– Wall Washer (product)
  3. #5750/861 LED50 / #5751/861 LED50/100 – Wall Mount / Wall Wash (product)
  4. #5750/855-11-ESW LED50 / #5751/855-11-ESW LED50/100 – Includes ESW / Swivel to allow 180° multi-angle positioning (product)
  5. #5750/850 LED50 / #5751/850 LED50/100 LED– Includes our #850 gooseneck arms for off-wall extension (product)
  6. #5750 (Pendant) LED50 / #5751 (Pendant) LED50/100 – Hanging Pendant (product)
  7. #5750/852 ESW LED50 / #5751/852 ESW LED50/100 – Rooftop mount. Includes 180° ESW / Swivel mount (product)



TechSpecs

 #5751 (Head)

Linear Light #5744

⚙ Primelite Catalog: #5751WW

⚙ TypeLinear Light Head

⚙ Lamps: LED50 (7,795 Lumens) | LED100 (14,000 Lumens) | 3.5K, 5K

⚙ LED Driver: Included

⚙ LensAcrylic | White | Clear | Frosted

⚙ Size: L 975/8” | Ht 6″ | W 45/8

⚙ Construction: Aluminum

⚙ Installation: Exterior | Sign Lighting, Wall Washing

⚙ Finishes: Choice of 29 powder coated colors. Custom finish upon request.

 #5796

Linear Light #5796

⚙ Primelite Catalog: #5796 (8″) | #5748 (4″)

⚙ TypeLinear Light

⚙ Lamp: #5748 – LED26 (3500K / 4010 Lumens) | 5000K / 4110 Lumens)

Lamp: #5796 LED52 (3500K / 8020 Lumens) | 5000K / 8220 Lumens)

⚙ LED Driver: Included

⚙ LensAcrylic | Clear

⚙ Size: #5748 – L 54″ | H 7″ (4′)

⚙ Size: #5796 – L 105″ | H 7″ (8′)

⚙ Construction: Aluminum

⚙ Installation: Exterior | Sign Lighting, Wall Washing

⚙ Finish: White







Copyright 2022 Primelite Mfg.







Posted on

Good Things, Do, Come in Smaller, Linear, Packages

linear post light #5744/4-1862
Our New Linear Lighting 2' Fixtures. Small But Mighty!





“These spectacular little vessels of illuminance are … stylish, functional and affordable”



2′ Linear Lights



Primelite Mfg, once again at the forefront of innovation, inspiration and motivation, introduces the latest in an expanding selection of Linear Lighting, our new 2 foot Linear Lights. These spectacular little vessels of illuminance are ready, willing and able to offer the best in stylish, functional and affordable illumination.



And Remember, “Good things, do, come in small packages”!





Small but mighty!



2' Linear Lights
A look at some of Primelite’s new 2′ Linear Lights



2′ Linear Lights Pack a Punch



Our new 2′ Linear Lights pack an illuminating punch when it comes to actual light output. The LED25 diode strip, might only be 24″ long,  but its output offers a broad field of light far beyond its small footprint. As an example, when mounted on a 7′ post, the output is equivalent to at least a 10′ spread of light. Proving once again, it might be small, but it’s mighty brighty!



Our New Linear Lighting 2' Fixtures. Small But Mighty!



Whether crafted as a pendant suspended sturdily from above or a post light mounted securely atop its post or pole, every fixture offers its own stylish interpretation of the best of linear lighting. Small, secure and weather-strong offering a respectable illumination to rival the bigger guys.



The “illumination effect (of Linear Lighting) is subtle, with a soft, uniform, highly efficient glow of light…It has no seams or glare so the focus is on light, not light sources. It’s energy efficient, simple to install, and easy to maintain.”



This week we are featuring the first fixtures from the 2′ Linear Light Series, Post Linear Light #5744/4-1862 and its fraternal twin #5744/4-1862-ESW. With its 24″ head (#5744A) mounted with one of our popular, and classic, arms #1862, this duo epitomizes the strength, style, and function of our new Linear Lighting fixtures. They‘re small but mighty, and bright as any big brother.



linear light #5744-1862



2′ Linear Light #5744/4-1862



linear light #5744/4-1862Post Linear Light #5744/4-1862 : a perfect light fixture, physically smaller, but with oversized lighting. Ideal for commercial lighting and general illumination; install in small areas that need big light. Where bright output is needed, but when the environment is tight.



With a light box of 24″, it comes complete with a LED25 strip of integrated diodes offering a bold output of bright, safe light.



And while shown with a clear lens (-4), your order comes with a choice of a lens color, white, clear or frosted. The fixture is weather rated for general exterior installations.



our 2′ Linear Lights ensure a long lasting, energy efficient and cost effective solution to your lighting design needs.





linear light #5744/4-1862Post Linear Light #5744/4-1862-ESW : The fraternal twin offering the same size, structure and illuminance of #5744/4-1862. But with the added benefit of a 90° swivel (ESW), offering a more precise angle of light.









Our linear lamps are handcrafted and assembled in our New York warehouse and offer years of stylish reliability. Constructed of strong aluminum, our lights are cost effective and budget friendly. All fixtures include integrated LEDs and drivers, while offering a very efficient lumens per watt! Introduce a touch of color with any of our 29 powder coated colors, including chic metallic-style finishes: nickel, chrome, bronze, brass, galvanized and more.

TechSpecs



 #5744/4-1862

Linear Light #5744/4-1862
Primelite Catalog: #5744/4-1862

Type: Post Light | Linear Light

Lamp: LED25 | 24″ LED Diode Strip

Lens: White | Clear | Frosted

Size: 24″ L x 16 1/2″ Ext x 25 1/2″ H

(ESW) 24″ L x 16 1/2″ Ext x 25 1/2″ H

Construction: Aluminum

Mounted: 3″ Posts | Poles

Installation: Smaller, Tight Exterior Spaces | Wall Wash
Finishes: Choice of 29 powder coated colors. Custom finish upon request.
Technical Drawing: #5744/4-1862

 #5744/4-1862-ESW

Linear Light #5744/4-1862-ESW
Primelite Catalog: #5744/4-1862-ESW

Type: Post Light | Linear Light

Lamp: LED25 | 24″ LED Diode Strip

Lens: White | Clear | Frosted

Swivel: 90° swivel | ESW

Size: 24″ L x 16 1/2″ Ext x 25 1/2″ H

(ESW) 24″ L x 16 1/2″ Ext x 25 1/2″ H

Construction: Aluminum

Mounted: 3″ Posts | Poles

Installation: Smaller, Tight Exterior Spaces | Wall Wash
Finishes: Choice of 29 powder coated colors. Custom finish upon request.
Technical Drawing: #5744/4-1862 ESW







Copyright 2021 Primelite Mfg.







Posted on

Become Dependent On da’ Pendants

Low Profile Can Pendant #56

Low Profile Can Pendant #56
Kitchen Color: Low Profile Can Pendant #56





Our Dependable Pendants





Our new Low Profile Can #56 Collection offers affordable, maintenance-free, easy installation and features Primelite’s superior construction. Inspired by our 6″ #56 Can, these fixtures range from ceiling-hung Pendants to generous interpretations of our Gooseneck silhouettes.





When we introduced our latest collection – the #56 Series – we offered a general look at what’s new. With 12 stunning new fixtures to discover, we will be highlighting each in the weeks ahead.





We’ll begin by highlighting the Pendants of the Series, #56 and #56/18. Similar in style and illumination, the Pendants were designed to bring the utilitarian simplicity and illumination of the Low Profile Can #56 to different spaces and environments.





Can Light Pendant #56 installed in a kitchen
Highlighting the silhouette simplicity of Can #56 Pendants





Pendant #56

Low Profile Can Pendant #56

Pendant #56, is not only a new inclusion to our Low Profile Can Collection but a new addition to the Primelite family of lighting fixtures. With its simple utilitarian shape and integrated LED, Pendant #56 is a bright spot in any commercial or residential installation.





Once installed, with its included vinyl cord, the pendant offers a humble and compact shape. Pendant #56 acts as an accent, both individually or in multiples. Imagine a trio of Pendants #56 suspended over, and illuminating a kitchen island or counter. Whether brightening marble, poured concrete, or unpretentious chopping block, Pendant #56 makes itself welcome to any project.





pendant Light #56/18
Exterior Highlights: Low Profile Can Pendant #56/18





Pendant #56/18

Pendant #56/18

Pendant #56/18 offers the illumination and simple design of its brother, Pendant #56, but with a waterproof construction that can be installed outside and exposed to the elements. With its waterproof construction, you can now add a touch of color and light to any exterior space; outdoor kitchens, patios, porches, even gazebos and verandas.





Pendant #56/18 comes with an 18″ stem, which allows both a strong and waterproof installation.





Both pendants, #56 and #56/18, of our Low Profile Can Collection consist of smartly designed and modern constructionHandmade by experienced craftsmen in our New York warehouse, each piece is hand-assembled and pre-tested to ensure you receive the best that Primelite can offer.





Low profile Pendants #56 and #56/18
Low Profile Can #56 Collection Pendants #56 & #56/18





The Low Profile Can #56 Collection consists of 12 new fixtures:



  1. #56AThe Low Profile Can. The inspiration of this series
  2. #56 – Interior Pendant, w/ 10′ vinyl cord
  3. #56/18 – Interior/Exterior Pendant w/ 18″ stem
  4. #56/859 – Gooseneck Can Light w/ arm #859
  5. #56/859 ESW – Gooseneck Can Light w/ arm #859 & 90° swivel
  6. #56/62 – Wall Mounted Can Light
  7. #56/850 – Gooseneck Can Light featuring our most popular arm, #850
  8. #56/850 ESW – Gooseneck Can Light, w/ arm #850 & 90° swivel
  9. #56/873 – Wall Mounted Can Light
  10. #56/864 – Gooseneck Can Light
  11. #56/855-12 – Gooseneck Can Light
  12. #56/858-12 – Gooseneck Can Light, w/ double #56 Cans





Primelite Mfg’s new Low Profile Can #56 Collection offers affordable, maintenance free and superior constructed fixtures. Along with the savings of long lasting LED lighting. And remember, the collection is available in any of our 29 powder coated colors, or can be custom finished to your design specifics.







Tech ⚙️ Specs
Low Profile Can Pendant #56 Pendant #56/18

Catalog:  #56

Style: Pendant | Interior

Size:  Dia. 5″ | Ht. 5″

Shade: Aluminum (spun)

Cord: 10′ | Vinyl | Black or White

Lamp:  LED12 | LED22 | Incandescent: 100W

Finishes:  Choose from 29 powder coated colors | Custom finishes available upon request

Technical Drawing: Pendant #56

Catalog:  #56/18

Style: Pendant | Interior | Exterior

Size:  Dia. 5″ | Ht. 5″

Shade: Aluminum (spun)

Stem: 18″

Lamp:  LED12 | LED22 | Incandescent: 100W

Finishes:  Choose from 29 powder coated colors | Custom finishes available upon request














© 2022 Primelite Mfg.







Posted on

Our Post Lights Bright the Night Skies Right

Post Lights #116/16-1595

Post Lights #116/16-1595





Our latest Post Light… brings a Dark Sky friendly illumination to exterior projects and installations





Post Light #116/16-1594 LED



Post Light #116/16-1595



Our latest Post Light, #116/16-1595 LED, brings a Dark Sky friendly illumination to exterior projects and installations.





Dark Sky friendly lighting ensures our lights are night bright safe, while helping to relieve the over-saturation of urban night glow.



Further helping the planet, and your budget, our lights come with a choice of energy efficient LED options – LED22, LED40 and LED68; 1800, 5100, and 7712 lumens, respectively.





Remember, use Dark Sky friendly lighting responsively, to brighten your world, not our planet!







Our Post Lights… are built to withstand the worst weather conditions, efficiently, while safely brightening your world







Post Lights #116/16-1595
Post Light #116/16-1595. Mounts on 3″ posts or existing posts w/ the addition of a pier mount





3″ Aluminum Posts





Our post lights fit any of Primelite’s 3″ Aluminum Posts. Available in Square, Round and “Spun” with smooth and fluted selections. In heights from 2′ – 20′, with an option for height customization. We also offer a selection of post accessories to complete your order.





Manufactured of 100% aluminum, our Post Lights, including #116/16-1595 LED, are built to withstand the worst weather conditions, efficiently, while brightening your world.





Primelite Mfg 3" aluminum posts
Primelite Mfg’s 3″ Aluminum Posts





Pier Mounts





pier mount #116/16-1595
Use Pier Mount #4 to mount this light on existing square posts



A Pier Mount is an adaptor cap that mounts atop an existing post, pier or pole, allowing the installation of any of Primelite’s Post Light fixtures, including the new #116/16-1595 LED.







Installing a post light into an existing post environment requires one of our Pier Mounts. Pier Mount #4 is designed for existing square posts. Pier Mount #5 is for round posts. While Pier Mount #2 is specifically designed  for plastic fence posts.









With its stylish silhouette and dependable energy efficiency, you’ll find Post Light #116/16-1595 LED to be a true workhorse







With its stylish silhouette and dependable energy efficiency, you’ll find Post Light #116/16-1595 LED to be a true workhorse. Constructed and assembled in our New York warehouse, our Post Lights are designed to withstand years of use, reliably and consistently, and would be a smart addition to any exterior lighting project.







Remember, use Dark Sky friendly lighting responsively, to brighten your world, not our planet!









Tech⚙Specs : Post Light

Post Lights #116/16-1595

⚙️Primelite Catalog: #116/16-1595 LED

⚙️Type: Post Light | Pier Mount Light

⚙️Size: Dia 16 1/2” | Ht 9 1/2”

⚙️Shade: 16″ Dia | Height 7″

⚙️Lens: Acrylic | Clear

⚙️Fits: 3″ Aluminum Posts | Pier Mounts #2, #4, #5

⚙️Lamp: LED |Dark Sky Friendly

          LED22 (1800 Lumens = 100W Incandescent) | 3K, 4K

          LED40 (5100 Lumens = 125W Metal Halide) | 3K, 4K

          LED68 (7712 Lumens = 175W Metal Halide) | 3K, 4K

⚙️Construction: Shade & Body – 100% Aluminum

⚙️Finishes: Choice of 29 powder coated colors. Custom finish upon request.

⚙️Technical Drawing: #116/16-1595 LED







Tech⚙Specs : Pier Mount



pier mounts #2, #4, #5

⚙️Primelite Catalog: #4

⚙️Type: Pier Mount

⚙️Adaptor Type: Square Post to 3″ Round Post*

⚙️Size: Ht 2 1/4” | W 3 1/2” | Custom Height and Diameter Available

⚙️Mounts To: Existing Square Post

⚙️Adaptor Fits: Any 3″ Diameter Post Light

⚙️Construction: 100% Aluminum





* Fits any of our 3″ Posts

⚙️Primelite Catalog: #5

⚙️Type: Pier Mount

⚙️Adaptor Type: Large Round Post to 3″ Round Post*

⚙️Size: Dia 6″ | Ht 6″ | Custom Height and Diameter Available

⚙️Mounts To: Existing 6″ Round Post

⚙️Adaptor Fits: Any 3″ Diameter Post Light

⚙️Construction: 100% Aluminum



* Fits any of our 3″ Posts

⚙️Primelite Catalog: #2

⚙️Type: Pier Mount

⚙️Adaptor Type: Square Plastic Fence Post to 3″ Round Post*

⚙️Size: W 4 3/4” Square | Ht 4 1/4” | Custom Height and Diameter Available

⚙️Mounts To: Existing 4″ Square Plastic Post or Fence Post

⚙️Adaptor Fits: Any 3″ Diameter Post Light

⚙️Construction: 100% Aluminum

* Fits any of our 3″ Posts















Copyright 2021 Primelite Mfg.







Posted on

Pier Mounts and Post Lights!

PIER Mounts and Posts. Posts and Pier Mounts

Primelite #116/16-1594
Color, Light, Style, Graffiti – Post Light #116/16-1594 LED





And Post Lights and Pier Mounts!





Primelite Mfg’s Post Lights are very versatile fixtures. Designed to fit our 3″ aluminum posts, we’ve found that many of your projects include existing posts and poles. Installing our Pier Mounts can easily transform an existing post into a Primelite ready mount!





Whether square post or round post, whether home on the range or backyard building, our Pier Mounted Post Lights, on post or pole, will satisfy the illumination of your needs.





Post Light #116/16-1594
Pier Mounts and Post Lights. Post Light #116/16-1594 LED w/ Pier Mount #4 (left) | Aluminum Post #6100 Series (center) | Pier Mount #5 (right)





Pier Mounts





Pier Mounts, which are adaptor caps that mount atop an existing post, pier or pole, allows the installation of our Post Light fixtures, including the new #116/16-1594 LED, into an existing posted environment.





Of our numerous Pier Mounts, Pier Mount #2 is designed to fit atop an existing square post while Pier Mount #5 is for your round posts. We even offer a Pier Mount #4, thats specifically designed  for plastic fence posts. Whatever you’ve got, we’ve got you converted.







Post Light #116/16-1594





Post Light #116/16-1594 LED



Our newest Post Light, #116/16-1594 LED, brings a Dark Sky friendly lighting to any project or installation. While at the same time helps combat the over-saturation of urban glow. Further helping the planet, and your pocketbook, our light comes with a choice of energy efficient LED options – LED22, LED40 and LED68; 1800, 5100, and 7712 lumens, respectively.



Bonus points! Post Light #116/16-1594 LED is Dark Sky friendly. Is economically LED. Has Primelite’s excellent quality and craftsmanship. Is classically styled. Is affordable, and, available in 29 powder coated colors!





Primelite Mfg 3" aluminum posts
Primelite Mfg’s 3″ Aluminum Posts



3″ Aluminum Posts



Made to fit any of our 3″ Aluminum Posts, and manufactured of 100% aluminum, our Post Lights, including #116/16-1594 LED, are built to withstand the worst of weather conditions, while efficiently and safely lighting your world.





Post Light #116/16-1594





With its stylish silhouette and energy efficiency, you’ll find Post Light #116/16-1594 LED to be a true workhorse. Our Post Lights are reliable, able to withstand years of use and will be a brilliant addition to any lighting project.







Tech⚙Specs

Post Light #116/16-1594

⚙️Primelite Catalog: #116/16-1594

⚙️Type: Post Light

⚙️Size: Dia 16″ | Ht 15 1/2”

⚙️Shade: 16″ Dia

⚙️Lens: Acrylic | Clear

⚙️Fits: 3″ Aluminum Posts | Pier Mounts #2, #4, #5

⚙️Lamp: Dark Sky Friendly

     LED:

          LED22 (1800 Lumens = 100W Incandescent) | 3K, 4K

          LED40 (5100 Lumens = 125W Metal Halide) | 3K, 4K

          LED68 (7712 Lumens = 175W Metal Halide) | 3K, 4K

⚙️Construction: Shade & Body – 100% Aluminum

⚙️Finishes: Choice of 29 powder coated colors. Custom finish upon request.





























pier mounts #2, #4, #5

⚙️Primelite Catalog: #4

⚙️Type: Pier Mount

⚙️Adaptor Type: Square Post to 3″ Round Post*

⚙️Size: Ht 2 1/4” | W 3 1/2” | Custom Height and Diameter Available

⚙️Mounts To: Existing Square Post

⚙️Adaptor Fits: Any 3″ Diameter Post Light

⚙️Construction: 100% Aluminum





* Fits any of our 3″ Posts

⚙️Primelite Catalog: #5

⚙️Type: Pier Mount

⚙️Adaptor Type: Large Round Post to 3″ Round Post*

⚙️Size: Dia 6″ | Ht 6″ | Custom Height and Diameter Available

⚙️Mounts To: Existing 6″ Round Post

⚙️Adaptor Fits: Any 3″ Diameter Post Light

⚙️Construction: 100% Aluminum



* Fits any of our 3″ Posts

⚙️Primelite Catalog: #2

⚙️Type: Pier Mount

⚙️Adaptor Type: Square Plastic Fence Post to 3″ Round Post*

⚙️Size: W 4 3/4” Square | Ht 4 1/4” | Custom Height and Diameter Available

⚙️Mounts To: Existing 4″ Square Plastic Post or Fence Post

⚙️Adaptor Fits: Any 3″ Diameter Post Light

⚙️Construction: 100% Aluminum

* Fits any of our 3″ Posts















Copyright 2021 Primelite Mfg.







Posted on

Primelite’s #12/10-1594 Brightens Your World ????…

brighten your world, not the planet

Brighten your world, not the planet





Not The Planet!





What’s New? Dark Sky friendly? Energy efficient? Features Primelite quality? And reliability? Oh, and it comes in lotsa colors?





Primelite’s Post Light #12/10-1594 is what’s new! And Dark Sky friendly. And built with the Primelite quality and craftsmanship you’ve come to expect. Oh, and it comes in 29 powder coated colors!





Post Light #12/10-1594
Primelite Mfg’s Post Light #12/10-1594





Post Light #12/10-1594 brings Dark Sky friendly lighting to any project or installation, or as we like to say – “Brighten Your World, Not The Planet.” Our post light offers the necessary illumination needed. But at the same time, helps combat the over-saturation of urban glow.





Our post lights further help the planet, and your pocketbook, with a choice of 2 energy efficient LED lights – LED12 and LED22, 800 and 1800 lumens, respectively.





Primelite Mfg 3" aluminum posts
Primelite Mfg’s 3″ Aluminum Posts



Made to fit any of our 3″ Aluminum Posts and Pier Mounts, you’ll find the our newest post light brings a stylish, and unique, silhouette to any outdoor installation.





Manufactured of 100% aluminum, Post Light #12/10-1594 is built to withstand the worst of weather conditions, while efficiently and safely brightening your world.



And as with any of our lamps, #12/10-1594 is handcrafted and assembled in our New York warehouse. You’ll find these post lights cost effective and budget friendly. And did we mention “customizable“!





post light Post Light #12/10-1594 in the garden
Post Light #12/10-1594 illuminating the nighttime garden



With its stylish silhouette and energy efficiency, you’ll find Post Light #12/10-1594 to be a true workhorse. Our Post Lights are reliable, able to withstand years of use and a brilliant addition to your lighting projects.





Tech⚙Specs

post light #12/10-1594

Primelite Catalog: #12/10-1594

Type: Post Light

Size: Dia 10″ | Ht 131/2”

Shade: 10″ Dia

Fits: 3″ Aluminum Posts | Pier Mounts

Lamp: Dark Sky Friendly | LED12 (800 Lumens) | LED22 (1800 Lumens) | 3K, 4K

Construction: Shade & Body – 100% Aluminum

Finishes: Choice of 29 powder coated colors. Custom finish upon request.















Copyright 2021 Primelite Mfg.







Posted on

Socket to Me, Socket to Me …

floor Lamp #231/39-19

Floor Lamp #231/39-19 in the garden
Outside – Illuminate the porch, patio or garden with Lamp #231/39-19. Designed to withstand the elements.





Triple S⚙️cket to Me, Baby!!!



Introducing Floor Lamp #231/39-19, the one with the classic design and triple socket. You’ll find our lamp to be unique in both style and design, ensuring a perfect, and radiant, placement into any industrial, modern, loft-like or commercial environment.



floor lamp #231/39-19 in color



With an impressive 19″ dome-like shade and classic elegance, Floor Lamp #231/39-19 will introduce a strong retro vibe with its placement. Whether installed in residence, commercial space or outdoors, our floor lamps are designed to withstand the elements; both inside or out!



Lamp #231/39-19 includes a triple socket

Under its stylish dome, you’ll find a triple socket (Edison style) which affords you the use of “old-skool” incandescent bulbs, or newer “old-skool” styled LEDs. Truly ride those retro waves with clear LED bulbs, with their beautifully visual filaments.



You’ll find our floor lamps efficiently illuminate any space, whether at home, in the office, hotels or lofts. Anywhere classic style is needed.



#231/39-19 definitely brings a bit of that “old-skool” style and some of that “old-skool” class to any environment.



And don’t forget color! Enliven any space with our powder coated colors. Whether its to accent, complement or clash, a vibrant installation will definitely sparkle with this designers delight.



#231/39-19 definitely brings a bit of that “old-skool” style and some of that “old-skool” class to any environment.



Living room w/ floor lamp #231/39-19
Inside – Lamp #231/39-19 perfectly brightens the home environment



And as with any of our lamps, #231/39-19 is handcrafted and assembled in our New York warehouse. You’ll find them to be cost effective and budget friendly. And did we mention “customizable“!



We’re here, ready, willing and able to work with you to accent any room. Any interior. Any space. Any place!



floor lamp #231/39-19 in the garden
Outside – Lamp #231/39-19 works exceptionally well in the garden. Weather resistant and stylish. A designers dream.



And did we mention “customizable”!



While classically stylish and simply elegant, you’ll find Floor Lamp #231/39-19 to be a true workhorse. Our lamps are reliable, able to withstand years of use and a brilliant addition to your life.





Tech⚙Specs

floor Lamp #231/39-19 floor Lamp #231/39-19



Primelite Catalog: #231/39-19

Type: Floor Lamp

Shade: 19″ | Dome | 100% Aluminum

Socket: Triple Socket (Edison Style)

Size: Couch Ht. 48″ | Torch Ht. 63″ | Customize Height

Bulb: “Old-Skool” Edison Lamp | LED Edison Lamp Style

Construction: Body – 100% Aluminum

Installations:
Industrial / Residential Interior | Residential Exterior |   Garden | Porch | Office Interior | Hotel Rooms

Finishes: Choice of 29 powder coated colors. Custom finish upon request.















Copyright 2021 Primelite Mfg.
