Sale!

RLM Shade on Standard Arm

Our #23/850 features a classic RLM barn shade on a standard gooseneck arm. This is one of our most popular and versatile gooseneck designs.

Catalog # 23/850 Series

Product price
Additional options total:
Order total:
Request a Quote
Categories: , ,

Description

Catalog #23/850 Series

Arm Dimensions: 22″ extension with a 6″ drop and 8.5″ overall height. Crafted from 1/2″ IPS schedule 40 pipe, with a 7/8″ outside diameter. Features a 90° front bend. Includes a 4″ cast canopy for octagonal junction box. Junction box sold separately.

Shade Dimensions: Multiple sizes available, see Product Details tab for more details.

Construction: Aluminum.

Finish Options: Choice of 29 powder-coated color options. Custom finish upon request.

Lamp Options: Choice of incandescent or LED, see Product Details tab for more details.

Also Available: With Swivel – #23/850 ESW Series.

Our #23/850 Series of gooseneck light fixtures is among our top-selling and most adaptable designs. The classic RLM barn warehouse style shade will match perfectly with a variety of different design aesthetics in both commercial and residential settings. Hand crafted in the USA from sturdy aluminum, and UL-listed for damp environments, these durable lights are rust-proof and ideal for beautifying any outdoor area. The fixture comes equipped with a heat-resistant porcelain socket and a 4-inch cast canopy that easily attaches to any 4-inch octagonal junction box. You can customize the fixture with your choice of shade diameter, lamp, and finish.



Custom Options Available! Contact Us for a Quote

Product Details

Catalog # Description Technical Drawing
#23/14-850 Overall Dimensions: 13.75″ diameter | 14″ height | 30″ extension

Shade Head Dimensions: 13.75″ diameter | 8″ height

Designed for use with a medium (E26) base incandescent lightbulb of up to 150 Watts (bulb not included). LED bulbs are available for purchase.

Technical Drawing
#23/14-850 LED12 Overall Dimensions: 13.75″ diameter | 14″ height | 30″ extension

Shade Head Dimensions: 13.75″ diameter | 8″ height

Integrated 12 Watt LED chip with a 50,000-hour bulb life. 1,100 lumen output. 120 Volts. Choice of 3K or 4K. Electronic dimming – list of compatible dimmers.

Technical Drawing
#23/14-850 LED22 Overall Dimensions: 13.75″ diameter | 14″ height | 30″ extension

Shade Head Dimensions: 13.75″ diameter | 8″ height

Integrated 22 Watt LED chip with a 50,000-hour bulb life. 2,000 lumen output. 120 Volts. Choice of 3K or 4K. Electronic dimming – list of compatible dimmers.

Technical Drawing
#23/16-850 Overall Dimensions: 16″ diameter | 15″ height | 31″ extension

Shade Head Dimensions: 16″ diameter | 9″ height

Designed for use with a medium (E26) base incandescent lightbulb of up to 200 Watts (bulb not included). LED bulbs are available for purchase.

Technical Drawing
#23/16-850 LED12 Overall Dimensions: 16″ diameter | 15″ height | 31″ extension

Shade Head Dimensions: 16″ diameter | 9″ height

Integrated 12 Watt LED chip with a 50,000-hour bulb life. 1,100 lumen output. 120 Volts. Choice of 3K or 4K. Electronic dimming – list of compatible dimmers.

Technical Drawing
#23/16-850 LED22 Overall Dimensions: 16″ diameter | 15″ height | 31″ extension

Shade Head Dimensions: 16″ diameter | 9″ height

Integrated 22 Watt LED chip with a 50,000-hour bulb life. 2,000 lumen output. 120 Volts. Choice of 3K or 4K. Electronic dimming – list of compatible dimmers.

Technical Drawing
#23/19-850 Overall Dimensions: 19.5″ diameter | 16.5″ height | 33″ extension

Shade Head Dimensions: 19.5″ diameter | 10.5″ height

Designed for use with a medium (E26) base incandescent lightbulb of up to 200 Watts (bulb not included). LED bulbs are available for purchase.

Technical Drawing
#23/19-850 LED12 Overall Dimensions: 19.5″ diameter | 16.5″ height | 33″ extension

Shade Head Dimensions: 19.5″ diameter | 10.5″ height

Integrated 12 Watt LED chip with a 50,000-hour bulb life. 1,100 lumen output. 120 Volts. Choice of 3K or 4K. Electronic dimming – list of compatible dimmers.

Technical Drawing
#23/19-850 LED22 Overall Dimensions: 19.5″ diameter | 16.5″ height | 33″ extension

Shade Head Dimensions: 19.5″ diameter | 10.5″ height

Integrated 22 Watt LED chip with a 50,000-hour bulb life. 2,000 lumen output. 120 Volts. Choice of 3K or 4K. Electronic dimming – list of compatible dimmers.

Technical Drawing
#23/24-850 Overall Dimensions: 24″ diameter | 17″ height | 35″ extension

Shade Head Dimensions: 24″ diameter | 11″ height

Designed for use with a medium (E26) base incandescent lightbulb of up to 200 Watts (bulb not included). LED bulbs are available for purchase.

Technical Drawing
#23/24-850 LED12 Overall Dimensions: 24″ diameter | 17″ height | 35″ extension

Shade Head Dimensions: 24″ diameter | 11″ height

Integrated 12 Watt LED chip with a 50,000-hour bulb life. 1,100 lumen output. 120 Volts. Choice of 3K or 4K. Electronic dimming – list of compatible dimmers.

Technical Drawing
#23/24-850 LED22 Overall Dimensions: 24″ diameter | 17″ height | 35″ extension

Shade Head Dimensions: 24″ diameter | 11″ height

Integrated 22 Watt LED chip with a 50,000-hour bulb life. 2,000 lumen output. 120 Volts. Choice of 3K or 4K. Electronic dimming – list of compatible dimmers.

Technical Drawing



Color Options

Primelite in Color!
Primelite offers a wide selection of colors, 29 dazzling colors! From red, blue, yellow, orange, to our painted metallic finishes; chrome, galvanized, soft nickel and more. All available at no additional cost, except for Verdi Green Rub. Primelite will also work with you when a custom color is needed. Send us a paint chip or a pantone color, and Primelite will deliver the perfect fixture, color and finish!
Colors (powder coated): White, Matte White, Almond, Gray, Black, Black Gloss, Yellow, Orange, Red, Burgundy, Pink, Light Blue, Dark Blue, Navy Blue, Turquoise, Green, Hunter Green, Verdi Green, Soft Nickel, Aluminum, Chrome, Gold, Antique Brass, Copper, Galvanized, Bronze, Bronze Tone, Brown and Verdi Green Rub.
