Posted on July 12, 2022July 14, 2022 by Louie Volpe

Low Profile, High Illumination Goosenecks

New-s-neck Versions of Our

Good ‘Ol Goosenecks

Low Profile Can #56 Collection

Primelite’s Low Profile Can #56 Collection features smartly designed lights that offer affordability, efficiency, are maintenance free, and offer easy installation. These fixtures have been inspired by the compact low profile #56 Can in styles ranging from ceiling hung Pendants to stylish interpretations of our Gooseneck silhouettes.

Our Goosenecks were designed to bring the utilitarian simplicity and efficient illumination of the Low Profile Can #56 to different places, spaces and environments

This week we’re highlighting additional Goosenecks from our collection. Specially Goosenecks #56/850 and #56/850-ESW. Compact yet strong fixtures featuring the low profile #56 can and our popular gooseneck arm #850.

You’ll find Gooseneck #56/850-ESW expands the flexibility of these fixtures with the addition of a 90° swivel. Allowing the precise angle for the perfect illuminating output. Both fixtures are now available with LED and incandescent options.

Our Goosenecks were designed to bring the utilitarian simplicity and efficient illumination of the Low Profile Can #56 to different places, spaces and environments.

Low Profile Gooseneck #56/850 | #56/850 LED12 | #56/850 LED22

With its simple utilitarian shape, compact size and energy efficiency, Gooseneck #56/850 would be a bright spot in any exterior installation

Gooseneck #56/850 is a simple and compact fixture. Mounted atop one of our most popular gooseneck arms. With a simple utilitarian shape, compact size and energy efficiency, Gooseneck #56/850 would be a bright spot in any exterior installation.

The Gooseneck #56/850 family is now available in 3 light options: Incandescent (E26 socket), LED12, LED22. The LED options offer 950 and 1850 Lumens respectively, and are available in 3K or 4K. Gooseneck #56/850 is also weather resistant insuring Primelite reliability, strength and function in any exterior environment.

Low Profile Gooseneck #56/850-ESW | #56/850-ESW LED12 | #56/850-ESW LED22

Gooseneck #56/850-ESW, but with the added addition of a 90° swivel … offers extra mobility allowing you to aim the light to a precise angle, ensuring an accurate and reliable illumination

Our Gooseneck #56/850-ESW offers the same functionality and design of its sister #56/850, but with the added addition of a 90° swivel. This swivel offers extra mobility allowing you to aim the light at a precise angle, ensuring an accurate and reliable illumination.

The Gooseneck #56/850-ESW family is also available in 3 light options: Incandescent (E26 socket), LED12, LED22. The LED options offer 950 and 1850 Lumens, respectively, and are available in 3K or 4K.

Our Low Profile Can Collection, including both Goosenecks, #56/850 and #56/850-ESW, consists of smartly designed, energy efficient (LED) models, offering weather reliability through modern construction and the latest LED components.

Handmade by experienced craftsmen in our New York warehouse, each light fixture is hand assembled and comes pre-tested. An easy installation completes our relibiliaty and ensures you receive the best that Primelite can offer.

Low Profile Can #56 Collection

The Low Profile Can #56 Collection consists of 12 new fixtures:

#56A – The Low Profile Can. The inspiration of this series
#56 – Interior Pendant, w/ 10′ vinyl cord
#56/18 – Interior/Exterior Pendant w/ 18″ stem
#56/859 – Gooseneck Can Light w/ arm #859
#56/859 ESW – Gooseneck Can Light w/ arm #859 & 90° swivel
#56/62 – Wall Mounted Can Light
#56/850 – Gooseneck Can Light featuring our most popular arm, #850
#56/850 ESW – Gooseneck Can Light, w/ arm #850 & 90° swivel
#56/873 – Wall Mounted Can Light
#56/864 – Gooseneck Can Light
#56/855-12 – Gooseneck Can Light
#56/858-12 – Gooseneck Can Light, w/ double #56 Cans

Primelite Mfg’s Low Profile Can #56 Collection offers affordable, maintenance free, superior constructed fixtures and energy efficiency LED options. The collection is available in any of our 29 powder coated colors, or can be custom finished to your design specifics. Our LED options come with a 5 year warranty for all LED components.

Our Low Profile Can Collection … consists of smartly designed, energy efficient (LED) models, offering … reliability through modern construction and the latest LED components

Tech ⚙️ Specs: Low Profile Collection



Catalog: #56/850 #56/850 LED12 #56/850 LED22 Style: Gooseneck \| Low Profile Fixture Size: Ht. 12 ^1/2″ \| Ext. 25 ^1/2” Shade #56: Dia. 6″ \| Ht. 4″ \| Aluminum (spun) Arm #850: Lht 22″ Lamp: LED12 (950 Lumens \| 3K,4K) \| LED22 (1850 Lumens \| 3K,4K) \| Incandescent: 100W Edison Bulb Finishes: Choose from 29 powder coated colors \| Custom finishes available upon request	Catalog: #56/850-ESW #56/850-ESW LED12 #56/850-ESW LED22 Style: Gooseneck \| Low Profile Fixture Size: Ht. 15 ^1/2″ \| Ext. 25 ^1/2” Shade #56: Dia. 6″ \| Ht. 4″ \| Aluminum (spun) Arm #850: Lht 22″ 90° Swivel: ESW Lamp: LED12 (950 Lumens \| 3K,4K) \| LED22 (1850 Lumens \| 3K,4K) \| Incandescent: 100W Edison Bulb Finishes: Choose from 29 powder coated colors \| Custom finishes available upon request

Posted on June 13, 2022June 14, 2022 by Louie Volpe

A Low Profile, High Illumination Gooseneck

***Good ‘Ol Gooseneck Is* *Now New-s-neck***

Low Profile Can #56 Collection

Our new Low Profile Can #56 Collection offers smartly designed fixtures with affordability, efficiency, are maintenance free, offer easy installation along with Primelite’s superior construction. Inspired by our compact 6″ #56 Can, these fixtures range from ceiling hung Pendants to bold interpretations of our Gooseneck silhouettes.

Our Goosenecks were designed to bring the utilitarian simplicity and efficient illumination of the Low Profile Can #56 to different places, spaces and environments

This week we’re highlighting two of the Goosenecks from this collection. Specially Goosenecks #56/859 and #56/859-ESW. Compact yet strong fixtures, our goosenecks are composed of the #56 can and gooseneck arm #859. Gooseneck #56/859-ESW expands their flexibility with the addition of a 90° swivel. Now allowing a precise angle for the perfect illuminating output. And both fixtures are now available with LED and incandescent options.

With similar style and illumination, our Goosenecks were designed to bring the utilitarian simplicity and efficient illumination of the Low Profile Can #56 to different places, spaces and environments.

Gooseneck #56/859 | #56/859 LED12 | #56/859 LED22

With its simple utilitarian shape, compact size and energy efficiency, Gooseneck #56/859 would be a bright spot in any exterior installation

Our Gooseneck #56/859 is a simple and compact fixture, composed of our #56 can and #859 gooseneck arm. With its simple utilitarian shape, compact size and energy efficiency, Gooseneck #56/859 would be a bright spot in any exterior installation.

The Gooseneck #56/859 family is now available with 3 light options: Incandescent (E26 socket), LED12, LED22. The LED options offer 950 and 1850 Lumens respectively, and are available in 3K or 4K.

Gooseneck #56/859 is weather resistant insuring Primelite reliability and function in any exterior environment.

Gooseneck #56/859-ESW | #56/859-ESW LED12 | #56/859-ESW LED22

Gooseneck #56/859, but with the added addition of a 90° swivel … offers extra mobility allowing you to aim the light to a precise angle, ensuring an accurate and reliable illumination

Our Gooseneck #56/859-ESW offers the same functionality and design of its sister, Gooseneck #56/859, but with the added addition of a 90° swivel. This swivel offers extra mobility allowing you to aim the light to a precise angle, ensuring an accurate and reliable illumination.

The Gooseneck #56/859-ESW family is also available in 3 light options: LED12, LED22, Incandescent (E26 socket). The LED options offer 950 and 1850 Lumens, respectively, and are available in 3K or 4K.

Our Low Profile Can Collection, including both Goosenecks, #56/859 and #56/859-ESW, consists of smartly designed, energy efficient (LED) models, offering weather reliability through modern construction and the latest LED components.

Low Profile Can #56 Collection

The Low Profile Can #56 Collection consists of 12 new fixtures:

#56A – The Low Profile Can. The inspiration of this series
#56 – Interior Pendant, w/ 10′ vinyl cord
#56/18 – Interior/Exterior Pendant w/ 18″ stem
#56/859 – Gooseneck Can Light w/ arm #859
#56/859 ESW – Gooseneck Can Light w/ arm #859 & 90° swivel
#56/62 – Wall Mounted Can Light
#56/850 – Gooseneck Can Light featuring our most popular arm, #850
#56/850 ESW – Gooseneck Can Light, w/ arm #850 & 90° swivel
#56/873 – Wall Mounted Can Light
#56/864 – Gooseneck Can Light
#56/855-12 – Gooseneck Can Light
#56/858-12 – Gooseneck Can Light, w/ double #56 Cans

Primelite Mfg’s new Low Profile Can #56 Collection offers affordable, maintenance free, superior constructed fixtures and energy efficiency (LED options). And remember, the collection is available in any of our 29 powder coated colors, or can be custom finished to your design specifics. Our LED options come with a 5 year warranty for all LED components.

Our Low Profile Can Collection … consists of smartly designed, energy efficient (LED) models, offering … reliability through modern construction and the latest LED components

Tech ⚙️ Specs: Low Profile Collection



Catalog: #56/859 #56/859 LED12 #56/859 LED22 Style: Gooseneck \| Low Profile Fixture Size: Ht. 12 ^1/2″ \| Ext. 19″ Shade #56: Dia. 6″ \| Ht. 4″ \| Aluminum (spun) Arm #859: Lght 16″ Lamp: LED12 (950 Lumens \| 3K,4K) \| LED22 (1850 Lumens \| 3K,4K) \| Incandescent: 100W Edison Bulb Finishes: Choose from 29 powder coated colors \| Custom finishes available upon request	Catalog: #56/859-ESW #56/859-ESW LED12 #56/859-ESW LED22 Style: Gooseneck \| Low Profile Fixture Size: Ht. 16″ \| Ext. 19″ Shade #56: Dia. 6″ \| Ht. 4″ \| Aluminum (spun) Arm #859: Lght 16″ 90° Swivel: ESW Lamp: LED12 (950 Lumens \| 3K,4K) \| LED22 (1850 Lumens \| 3K,4K) \| Incandescent: 100W Edison Bulb Finishes: Choose from 29 powder coated colors \| Custom finishes available upon request

Posted on March 10, 2022March 11, 2023 by Primelite

Up, Up And Away With Our Beautiful Cynthia

“3. 2. 1. Lift off. We have lift off.”

Primelite lifts off with another exciting addition to our “Sputnik Series”, Cynthia #685-27-5. While the fixtures in our Sputnik Series have been reminiscent of the clean lines of the early space days, “Cynthia,” in contrast, reworks those straight lines into a 27″ spheroid of circles and lights.

Perfect for stylishly modern restaurants, hotels, office spaces and conference rooms, as well as contemporary homes. Enhance Cynthia’s simple elegance with the addition of Edison style retro LED bulbs. For your convenience, Primelite offers the option of including these LED lamps with your order (for an additional price).

Featured Fixture Specs

Catalog: Cynthia, #685-27-5

Style: Pendant, Sputnik Series

Size: H 45″ | W 27″

Lamp: Edison Style, LED, Incandescent, PLT. (Recommended LED retro style) Quantity: 5

Construction: Steel

Commercial Installation: Hotel, Restaurants, Commercial Spaces, Office Conference Room, Common Spaces.

Residential Installation: Modern Homes: Entryways, Hallways, Modern Dining Rooms.

Finishes: Choice of 29 powder coated colors. Custom colors available. Shown: Bronze.

Technical Drawing: Cynthia, Pendant #685-27-5

Lamp: Edison Style Bulb: Incandescent, PLT, LED

(Recommended – LED Retro Style, sold separately)

Contact our office for more information.

Via Phone: 516-868-4411
Via our Contact Form

Primelite’s Online Catalog C (LED)
Check out our new online LED Catalog for our growing line of LED fixtures.

Primelite Manufacturing is your full-service lighting source. We carry much more than just Gooseneck, Angle Shades, and Sign Lighting. We offer Street lights, exterior poles and posts, replacement globes, stems, hi-hat extenders, and blank up kits. See our catalog for complete selections.

Posted on August 2, 2021 by Louie Volpe

Spotlight On: Linear Lights #5750/861 LED & #5751/861 LED

Spotlight on:linear light #5750/ 861 5750/861 LED

linear light #5750/861 — Primelite Linear Light #5750/851 LED & #5751/861 LED

With its integrated LED, #5750/ 861 LED and #5751/ 861 LED ensure a long lasting, energy and cost effective solution to your lighting projects and illumination design needs

It has always been Primelite Mfg.’s mission to bring our clients the latest in LED efficiency and lighting innovation. We follow this through by offering new, efficient, appealing, innovative and affordable lighting. As part of our new Linear Light Collection, Primelite Mfg. is proud to introduce fixtures that offer all of that, and more. Today we spotlight fixtures #5750/ 861 LED & #5751/ 861 LED.

Our Linear Lights have simple, elegant, modern designs that are ready to go. With an easy indoor or outside installation, our fixtures are tough, strong, budget friendly and energy efficient. These lights are a great option for many lighting projects.

The #5750 comes… with LED 50,… the #5751… in LED 50 or LED 100. That’s 7,795 and 14,000 lumens, respectively, offering a very effecient 140 lumens per watt!

Ideal for a wall wash, down lighting or general illumination, fixtures #5750/ 861 LED and #5751/ 861 LED come equipped with an installed driver, LED strip light and are available in 2 box lengths, 50″ and a 96″. The #5750 comes standard with LED 50, while the #5751 is available in LED 50 or LED 100. That’s 7,795 and 14,000 lumens, respectively, offering an efficiency of 140 lumens per watt!

Easily replace four smaller fixtures with just one of these linear lights. Our fixtures are handmade and assembled in Primelite’s New York warehouse. Linear Lighting fixtures #5750/ 861 LED and #5751/ 861 LED are crafted to withstand years of weather and storm abuse. Our lights are cost effective and budget friendly, and enjoy an easy and cost saving installation.

You’ll find our linear fixtures offer an excellent solution to any storefront, office exterior, warehouse, sign or billboard illumination project. Light fixtures #5750/ 861 LED and #5751/ 861 LED ensure a long lasting, energy and cost effective solution to your lighting projects and illumination design needs.

#5750/ 861 LED and #5751/ 861 LED are available in 2 sizes and LED configurations;

#5750 – Comes with a Light Box of 50″ and included LED 50 | 7795Lumens
#5751 – Comes with a Light Box of 96″ and choice of LED 50 | 7795Lumens or LED100 | 14,000Lumens

You order includes a choice of lens and light color. The acrylic lens are available in White, Clear and Frosted. LED light color available in 3.5K or 5K. Choose from any of our 29 powder coated colors or we can custom match to your colors.

The Linear Light Collection consists of 7 new fixtures. The #5750 and #5751 series include:

#5750F LED50 / #5751F LED50/100– Ceiling flush mount
#5750WW LED50 / #5751WW LED50/100– Wall Washer
#5750/861 LED50 / #5751/861 LED50/100 – Wall Mount / Wall Wash
#5750/855-11-ESW LED50 / #5751/855-11-ESW LED50/100 – Includes ESW / Swivel to allow 180° multi-angle positioning
#5750/850 LED50 / #5751/850 LED50/100 LED– Includes our #850 gooseneck arms for off-wall extension
#5750/ (Pendant) LED50 / #5751/ (Pendant) LED50/100 – Hanging Pendant
#5750/852 ESW LED50 / #5751/852 ESW LED50/100 – Rooftop mount. Includes 180° ESW / Swivel mount

TechSpec

Primelite Catalog: #5750/ 861 LED50

Size: Lth. 51^1/2” | Ht. 7^3/4″ | Ext. 14^1/2″

Light Box: 50″

Lamp: LED50 | 3.5k (warmer) or 5k (cooler) | 7,795 Lumens | 140 watts per Lumen

Lens: Acrylic | White, Clear, Frosted

Construction: Aluminum

Usage: Wall Wash

| Down Lighting

Installations: Commercial, municipal and retail interiors / exteriors, restaurants, office exteriors

Finishes: Choice of 29 powder coated colors. Custom finish upon request.

Technical Drawing: #5750/ 861 LED50

Primelite Catalog: #5750/ 861 LED50| #5751/ 861 LED100.

Size: Lth. 97^1/2” | Ht. 7^3/4″ | Ext. 14^1/2″

Light Box: 96″

Lamp: LED50 | 3.5k (warmer) or 5k (cooler) | 7,795 Lumens | 140 watts per Lumen

LED100 | 3.5k (warmer) or 5k (cooler) | 14,000 Lumens | 140 watts per Lumen

Lens: Acrylic | White, Clear, Frosted

Construction: Aluminum

Usage: Wall Wash

| Down Lighting

Installations: Commercial, municipal and retail interiors / exteriors, restaurants, office exteriors

Finishes: Choice of 29 powder coated colors. Custom finish upon request.

Technical Drawing: #5751/ 861 LED50 | #5751/ 861 LED100

*1 | *2 –Linear Lighting Frenzy

Posted on September 26, 2018 by Primelite

Best of Primelite: The Only Lights illuminating The Night Skies…

???? …Should Be Nature’s Own! ????

This Week’s featured fixtures are a “Best of Primelite”. Join us as we revisit some of our most popular LED Fixtures.

Primelite continues to “Brighten Your World”, while not contributing to light pollution, with the release of our Dark Sky “Friendly”* Post Light #1230/5 LED Series. Available in 3 configurations – LED40, LED48, and LED72 – the included LEDs are nestled in the fixture’s cap, avoiding uplight light-spill, and helping minimize any additional contribution to our planet’s light blight.

[Tweet “Primelite “Brightens Your World, Not the Planet ????“”]

Post Light #1230/5 LED Series offers pleasant illumination and is perfect in any urban, suburban or commercial exterior situation. Commercial and retail buildings, restaurants, office exteriors, parking lots and walkways would all benefit from the cost saving of our LED lights.

Post Light #1230/5 adds a sophisticated and classic silhouette to your exterior installations and fits any of our 3″ Aluminum Posts and Cast Aluminum Posts.

[Tweet “Together we can work to bring back the sky ???? for future generations”]

As with all our LED lights, once you add in power consumption savings, our Post Lights, with integrated LED systems, are as cost-effective as they are durable! Primelite Mfg offers a 5-year warranty on all our integrated LED systems (iLEDs)!

*Learn more about the Dark Sky initiative and the Dark Sky Association – IDA | International Dark Sky Association.

Tech⚙Specs

Catalog: Primelite #1230/5 LED Series

Style: Street Light, Post Light. Dark Sky* “Friendly”, Streetlight, Exterior

Size: Ht. 31″ | Wt. 17″

Lamp: LED40 | LED48 | LED72 – *iLEDs (Integrated LED System)

Construction:

Globe: Acrylic (frosted)

Base: Cast Aluminum

Cap: Aluminum

Installations: Commercial, municipal and retail exteriors, restaurants, office exteriors, parking lots, walkways, parks

Post: 3″ (Fits any of Primelite’s 3″ Aluminum and Cast Aluminum Posts)

Finishes: Choice of 29 powder coated colors. Custom finish upon request.

Technical Drawing: Post Light #1230/5 LED Series

Lamps: iLEDs (Integrated LED System)

LED10 x 4 = LED40

LED12 x 4 = LED48

LED18 x 4 = LED72

Please Note: iLEDs (Integrated LED system) is Primelite’s custom designed, and built, LED system used in our Street Lights

Contact our office for more information.

Via Phone: 516-868-4411
Via our Contact Form

Primelite’s Online Catalog C (LED)
Check out new online LED Catalog for our growing line of LED fixtures.

Posted on September 20, 2018 by Primelite

Best of Primelite: Don’t Lose your Pendant #423-10-4-LED12

This Week’s featured fixtures are a “Best of Primelite”. Join us as we revisit some of our most popular LED Fixtures.

With all the Pendant choices available, don’t go losing your pendant. Or your mind! Primelite is here to help. Choose a classic and stylish option from our large selection of LED Pendant lights. This week we are featuring the classic Jelly Jar Pendant #423/10. Fitted with our new LED12 module, and a clear glass jelly jar, the pendant adds a smart and stylish accent to any commercial or residential interior.

[Tweet “Our classic pendant will have interior designers swooning with retro-roused anticipation.”]

Imagine illuminating a cafe, coffee shop, restaurant, office, even a residential space, with a multiplicity of #423/10 LED Pendants. Most definitely a case of “more is definitely more!”

Primelite’s Pendants are available in a wide selection of colors, 29 dazzling colors in fact! All available in our tough, weather resistant, powder coated finish. From red, blue, yellow, orange, to our painted metallic finishes – chrome, galvanized, nickel and more. We can even match a designers color choice selection.

[Tweet ” More is definitely more!”]

And remember – once you add in the power consumption savings, our pendants, with integrated LED systems, are as cost-effective as they are durable! Primelite Mfg offers a 5-year warranty on all our integrated LED systems (iLEDs)!

Now, isn’t it time our lights brightened your life?

Tech⚙Specs

Catalog: #423/10-4 LED12

Style: Pendant | w/ Jelly Jar | Interior

Size: Dia. 10″ | Ht. 11″ (Additional Shade sizes available)

Jelly Jar: Glass | Clear (-4) | (Frosted -5)

Lamp: LED12 | 3K |900 Lumens

Cord: 10′ | Vinyl | Black or White

Construction: Shade: Aluminum (Spun) | Canopy: Aluminum

Finishes: Choose from 29 powder coated colors | Custom finishes available upon request

Technical Drawing (Cut Sheet):

Pendant #423/10-4

Stem #9002-12 (12″)

Lamp: iLEDs (Integrated LED System)

LED12 TYPE2 | 3K

Please Note: iLEDs (Integrated LED system) is Primelite’s custom designed, and built, LED lighting system.

Contact our office for more information.

Via Phone: 516-868-4411
Via our Contact Form

Primelite’s Online Catalog C (LED)
Check out our new online LED Catalog for our growing line of LED fixtures

Posted on September 12, 2018 by Primelite

Best of Primelite: Brighten Your World With Color By Primelite

This Week’s featured fixtures are a “Best of Primelite”. Join us as we revisit some of our most popular LED Fixtures.

When it comes to brightening your world, we know Primelite is the answer! But did you know that Primelite can also brighten your world with an additional touch of color? Why limit the palette of your projects to the same colors, when a world of color is available?

[Tweet “Primelite offers a wide selection of colors, 29 dazzling colors in fact!”]

Primelite offers a wide selection of colors, 29 dazzling colors in fact! All available in our tough, weather resistant, powder coated finish. From red, blue, yellow, orange, to our painted metallic finishes – chrome, galvanized, nickel and more – all are available at no additional cost!

Primelite will also work with your client or designer when a custom color is needed. Furnish us with a paint chip or a pantone color and Primelite will deliver the perfect fixture, color and finish!

And our colors are not limited to goosenecks. Our posts, street lights, post lights, pendants, globe hardware, most exterior and interior fixtures can be color -ized to bring the light, and some life, to any project.

[Tweet “Primelite can brighten your world with a touch of color”]

One example of Primelite’s color options, shown wearing our glorious red, is this week’s featured Gooseneck #116/12-859. Yes, of course, it’s available with an LED option, specifically LED12 or LED22 in 3K or 4K. Once you add in power consumption savings, our goosenecks, with integrated LED systems, are as cost effective as they are color-fully durable!

View Primelite’s Dazzling Selection of Color Finishes!

And remember – Primelite Mfg offers a 5 year warranty on all our integrated LED systems (iLEDs)!

⚙️TechSpecs:

Catalog: #116/12-859 LED12

Style: Gooseneck

Size: Dia 12″ | Ht. 12″ | Ext 22″

Shade / Head: Dia 12″ | Ht. 6″ (#116)

Arm: Ext. 16¾” (#859)

Lamp: LED12 *iLEDs (Integrated LED System), 800 Lumens, 3K/4K

Construction: 100% Aluminum | Shade: Spun Aluminum | Arm: Extruded Aluminum | Canopy: Cast Aluminum

Finishes: Choice of 29 powder coated colors. Custom finish upon request. Shown: Red

Technical Drawing (cut sheet)

Gooseneck #116/12-859 LED12

Lamp: (cut sheet)

LED12

Please Note: iLEDs (Integrated LED system) is Primelite’s custom designed, and built, LED lighting system.

Contact our office for more information.

Via Phone: 516-868-4411
Via our Contact Form

Primelite’s Online Catalog C (LED)
Checkout our new online LED Catalog for our growing line of LED fixtures

Posted on September 5, 2018 by Primelite

Best of Primelite: The Lighting Industry Marches to the Beat of the LED

~~Incandescent~~.❌~~Fluorescent~~.❌~~High Intensity Discharge~~.❌

This Week’s featured fixtures are a “Best of Primelite”. Join us as we revisit some of our most popular LED Fixtures.

As the lighting industry continues marching to the beat of the LED, Primelite is proceeding with its work to offer you the finest, and brightest, LED lighting solutions. Our new introduction this week, Globe Fixture #284-875, is now available in LED20 3K/4K (2,280-2,400 Lumens).

[Tweet “Primelite continues with its work to bring you the best, and most advanced, LED lighting solutions”]

Our wall mounted globe would offer perfect and stylish, illumination outside, or inside, any office complex, commercial space, warehouse, even illuminating a chic and funky restaurant or sophisticated retail space. Lighting Designers, Architects, Interior Designers will find the #284-875 LED20 a perfect solution to their commercial lighting projects.

Primelite continues to work, research and test new LED systems in order to bring you the latest in LED technology. With our new LED options, you can now offer your clients a technologically advanced, cost effective and stylish option for their commercial projects.

[Tweet “Lighting Designers, Architects, Interior Designers will find the #284-875 LED20 a perfect solution to their commercial lighting projects.”]

Technical Drawing: #284-875 LED20

Tech⚙️Specs:

Catalog: #284-875 LED20

Style: Wall Mount Globe

Size: Dia. 14″ | Ht. 29¾″ | Ext. 23½”

Globe: 14″ | Acrylic (#284)

Arm: Ht. 17¾” | Ext. 17½ (#875)

Lamp: LED20 (2 x LED10) *iLEDs (Integrated LED System), 3K – 2280 Lumens | 4K- 2400 Lumens

Construction: Arm: Aluminum | Globe: Acrylic

Finishes: Choice of 29 powder coated colors. Custom finish upon request. Shown: Black

Lamp: iLEDs (Integrated LED System)

LED10, 3K/4K

Please Note: iLEDs (Integrated LED system) is Primelite’s custom designed, and built, LED lighting system.

Contact our office for more information.

Via Phone: 516-868-4411
Via our Contact Form

Posted on August 21, 2018March 31, 2022 by Primelite

WATCH: Globe Series Pt1

Primelite MFG welcomes you to the first of our short informative Globe series.

In this Series we’ll be discussing and explaining all aspects of our Globes. In this Part 1 we will introduce you to the materials our globes are made of, such as; Glass, Acrylic, Polyethylene and Super Lex.

Please stay tuned for our next Globe Series and remember, we make it Light! we make it Bright! at Primelite!

Visit Us at Primelite-mfg.com

Posted on August 8, 2018 by Primelite

290

“Get Your Globe On!”

It’s time to Globe! It’s time to Glow! It’s time to get your Globe on, with our versatile and multifaceted Globes!

[Tweet “Globe Pendant #288/3 LED90…offers a classic yet spontaneous tone on any installation”]

This week we are featuring Globe Pendant #288/3 LED90, as classic as it can be and not boxed into any category! From elegant and sleek to fun and embellishing! This Globe is perfect for any interior installation: residential, commercial situations, restaurants, auditoriums, retail, etc.

Primelite’s Globe Pendants come in many different sizes and materials and are designed with style and practicality, offering a classic yet multifaceted globe!

And, as with all our LED options, once you add in power consumption savings, our globes & pendants, with integrated LED systems, are as cost-effective as they are durable! And remember – Primelite Mfg offers a 5-year warranty on all our integrated LED systems (iLEDs)!

[Tweet “It’s Glow time, Its Globe time”

Tech⚙Specs

Catalog: ???? #288/3 LED90

Type: Globe Pendant

Style: Globe

Size: 18″ (#288)

Globe: White Acrylic

Lamp: LED90 – iLEDs (Integrated LED System)

Cord: 10′ Vinyl, Black or White

Construction: Canopy & Ball Plate: Aluminum

Installations: Indoors; residential, commercial situations, restaurants, retail, etc.

Finishes: Choice of 29 powder coated colors. Custom finish upon request. Shown: Black

Technical Drawing (Cut Sheet):

Globe Pendant #288/3 LED90

Lamp: LED18 (5 x LED18)

Contact our office for more information.

Via Phone: 516-868-4411
Via our Contact Form

Primelite’s Online Catalog C (LED)
Check out our new online LED Catalog for our growing line of LED fixtures.

New-s-neck Versions of Our

Good ‘Ol Goosenecks

Low Profile Can #56 Collection

Low Profile Gooseneck #56/850 | #56/850 LED12 | #56/850 LED22

Low Profile Gooseneck #56/850-ESW | #56/850-ESW LED12 | #56/850-ESW LED22

Low Profile Can #56 Collection

Tech ⚙️ Specs: Low Profile Collection

Good ‘Ol Gooseneck Is Now New-s-neck

Low Profile Can #56 Collection

Gooseneck #56/859 | #56/859 LED12 | #56/859 LED22

Gooseneck #56/859-ESW | #56/859-ESW LED12 | #56/859-ESW LED22

Low Profile Can #56 Collection

Tech ⚙️ Specs: Low Profile Collection

“3. 2. 1. Lift off. We have lift off.”

TechSpec

Tech⚙Specs

Tech⚙Specs

Catalog: #423/10-4 LED12

Tech⚙️Specs:

Primelite MFG welcomes you to the first of our short informative Globe series.

In this Series we’ll be discussing and explaining all aspects of our Globes. In this Part 1 we will introduce you to the materials our globes are made of, such as; Glass, Acrylic, Polyethylene and Super Lex.

Please stay tuned for our next Globe Series and remember, we make it Light! we make it Bright! at Primelite!

Visit Us at Primelite-mfg.com

Tech⚙Specs

***Good ‘Ol Gooseneck Is* *Now New-s-neck***
